Antwerpen 14 August 2017 |
|
Name |
R.C. BEHAR |
|
Previous names |
2009 - 09/2009 Vinga |
|
Type |
Oil and chemical carrier |
|
IMO-number |
9413664 |
|
Call sign |
9HA2760 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
Previous flags |
2009 - 2011 Turkey |
|
GT |
3.997 t registered |
|
DWT |
Summer: 5.554 t Winter: 5.376,1 m³ |
|
NT |
1.840 t registered |
|
Length |
107,60 m overall 100,43 m between perpendiculars |
|
Breadth |
16,00 m |
|
Draught |
Summer: 6,00 m |
|
Air draft |
23,00 m |
|
Freeboard |
2.012 mm |
|
Speed |
Max: 15,5 knots Service: 13,0 knots |
|
Built |
2009 |
|
Keel laid |
07/10/2008 |
|
Delivery date |
28/08/2009 |
|
Builder |
Celiktekne Tersanesi Istanbul |
|
Yard number |
69 |
|
Hull material |
Ordinary strength steel High strength steel |
|
Hull type |
Double hull Double bottom |
|
Watertight bulkheads |
10 |
|
Main engine |
1x MAN B&W 6L32/40 - 4 stroke 6 cylinder 320 x 1.400 mm combustion engine 2.990 kW at 750 rpm Manufacturer: MAN B&W Diesel A/S |
|
Propellers |
1x Pitch propeller |
|
Boilers |
2x Auxiliary boiler - 10,0 bar 1x Exhaust gas boiler - 10,0 bar |
|
Shaft generator |
1x Leroy Somer 850 kW |
|
Generators |
3x Main diesel generatorsets Leroy Somer each 400 kW |
|
Emergency generator |
1x Diesel generatorset 108 kW |
|
Number of cargo tanks |
12 + slop tank |
|
Cargo tank capacity 98% |
6.520 m³ |
|
Segregation |
12 |
|
Number of pumps |
13x Cargo pumps |
|
Manifolds |
Manifold to deck: 1,57 m Manifold to stern: 57,00 m Manifold to bow: 50,00 m Manifold to rail; 2.250 mm |
|
Number of tanks |
Ballast: 13 Fresh Water: 8 Sludge: 6 Fuel Oil: 5 Diesel Oil: 4 Lubricating Oil: 3 Chain: 1 Hydraulic Oil: 1 Sewage: 1 Organic Compound: 1 Waste Water: 1 |
|
Tank capacities 100% |
Diesel Oil: 54,4 m³ / 48,96 t Freshwater: 326,54 m³ Fuel Oil: 282,27 m³ / 276,63 t Hydraulic Oil: 4,46 m³ Lube Oil: 13,7 m³ / 12,33 t Tank Ballast: 2.473,64 m³ / 2.535,48 t |
|
Lifting equipment |
1x Hose handling crane - SWL 5,0 t 1x Provision crane - SWL 2,0 t |
|
Crew size |
18 |
|
Manager |
Talos Shipping Limited |
|
Operator |
Ares Gemi Isletmeciligi A.S. Yeşilköy Mahallesi Atatürk Caddesi No:12/1 |
|
Registered owner |
Talos Shipping Limited |
|
Latest data adjustment |
13 March 2018 |
