Westerschelde 27 December 2017 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 27/12/17 | Westerschelde 27/12/17 | Westerschelde 27/12/17 | Westerschelde 27/12/17 | Westerschelde 17/03/19 | Westerschelde 28/01/16 | |||||
|
Name |
SEABASS |
|
Type |
Oil tanker |
|
IMO-number |
9251640 |
|
Call sign |
DLDY |
|
Flag |
Bremen |
|
Port of registry |
German |
|
Previous flags |
2009 - 2011 Germany 2011 - 2013 Liberia 2013 - 2014 Cyprus |
|
GT |
21.353 t |
|
DWT |
Summer: 32.445 t |
|
NT |
8.390 t |
|
Length |
177,77 m overall 168,00 m between perpendiculars |
|
Breadth |
28,16 m extreme |
|
Draught |
11,00 m |
|
Keel to mast end |
44,00 m |
|
Depth |
16,80 m |
|
Speed |
15,1 knots |
|
Built |
2001 |
|
Keel laid |
07/12/2000 |
|
Launch date |
04/08/2001 |
|
Date of completion |
01/11/2001 |
|
Builder |
Lindenau GmbH Schiffswerft & Maschinenfabrik Kiel Germany |
|
Yard number |
243 |
|
Hull material |
Steel |
|
Hull type |
Double hull Double bottom |
|
Watertight bulkheads |
4 |
|
Continuous decks |
1 |
|
Main engine |
1x MAN-B&W 6L58/64 - 4 stroke 6 cylinder 580 x 640 mm combustion engine 8.340 kW / 11.342 hp at 428 rpm |
|
Propellers |
1x Controllable pitch propeller - aft at 101,0 rpm |
|
Boilers |
1x Steam boiler, exhaust gas heated - 12,0 bar Heating surface: 78,0 m² 1 x Steam boiler, oil fired - 12,0 bar Heating surface: 115,0 m² Manufacturer: Alfa Laval Aalborg A/S |
|
Shaft generator |
1x 1.400 kW |
|
Generators |
3x Yanmar 6N21AL-GV main diesel generatorsets each 1.200 kW |
|
Emergency generator |
1x Deutz BF6M1015M diesel generatorset 200 kW |
|
Compressed air receivers |
2x Receivers each 1.000 litres - 30,0 bar 1x Receiver 20 litres - 30,0 bar 1x Receiver 1.000 litres - 10,0 bar 1x Receiver 60 litres - 10,0 bar |
|
Bow thruster |
1x Transverse thruster 1.050 kW, forward |
|
Number of cargo tanks |
10x Wing tanks |
|
Cargo tank capacity |
Liquid: 37.511 m³ |
|
Number of pumps |
10x Cargo centrifugal pumps each 500 m³/h |
|
Manifolds |
Manifold height above deck: 2,10 m Distance from bow to centre manifold: 85,00 m |
|
Tank capacities |
Fuel oil: 863 m³ Ballast: 16.717,7 m³ |
|
Anchor equipment
|
Length: 607,50 m Diameter: 66 mm |
|
ISM & commercial manager |
German Tanker Shipping GmbH & Co. KG Hans-Böckler-Straße 50 28217 Bremen Germany |
|
Registered owner |
TMS "SEABASS" Sea Tanker GmbH & Co. KG Care of German Tanker Shipping GmbH & Co KG Hans-Boeckler-Strasse 50 28217 Bremen Germany |
|
Renamed |
2021 Seabas Comoros, Comoros - Call sign: D6A2856 Owner & manager: Etihad Engineering & Marine Services FZC ,City of Sharjah - United Arab Emirates |
|
Latest data adjustment |
29 December 2023 |
