Westerschelde 06 October 2018 |
 |
 |
|
| Westerschelde 04/07/17 | Westerschelde 10/07/17 | |
|
Name |
BOW SIRIUS |
|
Type |
Tanker for chemicals and oil products |
|
IMO-number |
9215294 |
|
Call sign |
LACQ7 |
|
Flag |
Norway |
|
Port of registry |
Bergen |
|
Previous flags |
06/2006 -04/2007 Republic of Singapore, Singapore City - Call sign: LACQ7 |
|
GT |
29.965 t Suez: 31.206 t Panama: 24.888 t |
|
DWT |
Summer: 40.048 t |
|
NT |
15.032 t Suez: 26.983 t Panama: 24.903 t |
|
Lightship |
14.366 t |
|
Length |
182,88 m overall 175,25 m between perpendiculars |
|
Breadth |
32,21 m extreme |
|
Draft |
Summer: 11,52 m |
|
Keel to mast |
46,63 m |
|
Depth |
17,95 m |
|
Speed |
14,6 knots |
|
Built |
2006 |
|
Keel laid |
23/09/2005 |
|
Launch date |
17/06/2006 |
|
Date of completion |
15/12/2006 |
|
Builder |
Stocznia Szczecinska Nowa Sp.z.o.o. Szczecin Poland |
|
Yard number |
B588-III/7 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Bulkheads |
Transverse: 11 Longitudinal: 6 |
|
Main engine |
1x Wärtsilä 6RTA58T-B - 2 stroke 6 cylinder combustion engine 12.750 kW / 17.335 hp at 105,0 rpm |
|
Propellers |
1x Kamewa Ulstein controllable pitch propeller Diameter: 6.800 mm |
|
Boilers |
2x Auxiliary boiler, oil/gas fired AQ-18 1x Auxiliary boiler, exhaust gas heated AV-6N Manufacturer: Aalborg Industries A/S |
|
Generators |
3x MAN 6L28/32H main diesel engine each 1.500 kW coupled with AVK generators each 1.499 kVA |
|
Emergency generator |
1x MAN D2866 E/TE/LE diesel engine 218 kW coupled with AVK generator 250 kVA |
|
Bow thruster |
1x 1.000 kW |
|
Number of cargo tanks |
40 |
|
Number of segregations |
40 |
|
Cargo tank capacity 98% |
51.104 m³ |
|
Pumps |
27x Framo cargo pumps each 230 m³ 7x Framo cargo pumps each 330 m³ 6x Framo cargo pumps each 100 m³ |
|
Manifolds |
Summer draft to manifold: 8,70 m Rail to manifold: 4,70 m Bow to manifold: 92,94 m |
|
Tank capacities |
Ballast: 16.676,7 m³ |
|
Anchor equipment |
Length: 664,50 m Diameter: 76 mm |
|
Accommodation |
31 One man cabins |
|
ISM & commercial manager |
Odfjell Management AS Conrad Mohrsv. 29 Bergen Norway |
|
Operator |
Odfjell Tankers |
|
Owner |
Nordic Leasing Halifax United Kingdom |
|
Registered owner |
Odfjell Chemical Tankers AS Conrad Mohrs Veg 29 5072 Bergen Norway |
|
Latest data adjustment |
03 August 2024 |
