Name |
MINERVA TYCHI |
|
Type |
Care of Minerva Marine Inc , 141-143, Vouliagmenis Avenue & 1 Aiolou Street, Voula, 166 73 Athens, Greece. |
|
Main products |
Chemicals |
|
Transport type |
Isothermal |
|
IMO-number |
9723291 |
|
Call sign |
SVCD7 |
|
Flag |
Greece |
|
Port of registry |
Piraeus |
|
GT |
24.090 t registered |
|
DWT |
39.070 t |
|
NT |
10.389 t |
|
Displacement |
Lightship: 9.550 t |
|
Length |
184,47 m overall 176,00 m between perpendiculars |
|
Breadth |
27,40 m |
|
Draft |
11,91 |
|
Freeboard |
5.714 mm |
|
Depth |
17,60 m |
|
Speed |
Service: 14,4 knots Max: 17,5 knots |
|
Built |
2016 |
|
Keel laid |
26/09/2015 |
|
Date of completion |
04/02/2016 |
|
Builder |
Hyundai Mipo Dockyard Co., Ltd. South Korea |
|
Yard number |
2524 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Watertight compartments |
6 |
|
Continuous decks |
1 |
|
Main engine |
1x Hyundai/MAN-B&W 6S50ME-B - 2 stroke 6 cylinder 500 x 2.214 mm combustion engine 9.884 hp / 7.270 kW at 99,0 rpm Built: 06/10/2015 Builder: Hyundai Heavy Ind. Co., Ltd. - Engine & Mach. Div., Ulsan - South Korea |
|
Propellers |
1x Fixed pitch mono-block propeller - aft at 129,0 rpm |
|
Boilers |
1x Auxiliary boiler, oil/gas fired - 8,0 bar Heating surface: 233 m² 1x Auxiliary boiler, composite - 8,0 bar Heating surface: 213,4 m² Manufacturer: Kangrim |
|
Generators |
3x Hyundai 6H21/32 main diesel generatorsets each 900 kW Manufacturer: Hyundai Heavy Industries Co., Ltd. |
|
Emergency generator |
1x Cummins 6CT-8.3-D(M) diesel generatorset 120 kW |
|
Number of cargo tanks |
10 + 2 slop tanks |
|
Total tank capacity 98% |
42.712,3 m³ excluding slop tanks |
|
Total slop tank cap. 98% |
1.080,20 m³ |
|
Pumps |
10x Cargo pumps each 500 m³/h 2x Slop pumps cargo pumps each 300 m³/h 2x Spare pumps each 200 m³/h |
|
Tank capacities |
Ballast: 18.587,6 m³ Fuel oil: 1.175,9 m³ |
|
Anchor equipment |
Length: 632,50 m Diameter: 68 mm |
|
Lifting equipment |
1x Crane - SWL 10,0 t |
|
ISM & commercial manager |
Minerva Marine Inc. Par. Leof. Vouliagmenis 141 Vari Voula Vouliagmeni 166 73 Greece |
|
Registered owner |
Tribeca Trading S.A. Care of Minerva Marine Inc. 141 Vouliagmenis Avenue Voula, 166 73 Athens Greece. |
|
Latest data adjustment |
29 October 2023 |
