Antwerpen 15 May 2018 |
 |
| Antwerpen 15/05/18 |
|
Name |
UMGENI |
|
Previous names |
2011 - 04/2011 Siyanda 04/2011 - 08/2011 Umzimvubu |
|
Type |
Tanker for chemicals & oil products |
|
IMO-number |
9382499 |
|
Call sign |
9V9273 |
|
Flag |
Republic of Singapore |
|
Port of registry |
Singapore City |
|
Previous flags |
2011 - 2011 United Kingdom |
|
GT |
11.271 t |
|
DWT |
Summer: 16.500 t |
|
NT |
4.986 t |
|
Length |
144,00 m overall 135,60 m between perpendiculars |
|
Breadth |
23,00 m extreme |
|
Draught |
8,81 m |
|
Depth |
12,50 m |
|
Speed |
Service: 13,0 knots Max: 16,1 knots |
|
Built |
2011 |
|
Keel laid |
19/05/2008 |
|
Date of completion |
09/08/2011 |
|
Builder |
Taizhou Sanfu Ship Engineering Co. Ltd. |
|
Yard number |
SF050203 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Bulkheads |
Water tight: 4 Oil tight: 10 |
|
Continuous decks |
1 |
|
Main engine |
1x STX/MAN B&W 6S35MC-Mk7 - 2 stroke 6 cylinder 350 x 1.400 mm combustion engine 4.440 kW / 6.040 hp at 173 rpm |
|
Propellers |
1x Fixed pitch propeller Manufacturer: Nantong Shenggang Marine Propeller Co. Ltd. |
|
Boilers |
1x Auxiliary boiler, oil/gas fired - 7,0 bar 1x Auxiliary boiler, composite - 7,0 bar Manufacturer: Zhang Jiang Green Sha Zhou |
|
Generators |
3x Daihatsu 5 DK 20 main diesel generatorsets each 580 kW Manufacturer: Wuxi Fenxi Electrical Machine Co., Ltd. |
|
Emergency generator |
1x Cummins 6CT-8.3-D(M) diesel generatorset 118 kVA - 94 kW - 152 hp |
|
Bow thruster |
1x 505 kW |
|
Number of cargo tanks |
14 |
|
Cargo oil capacity |
19.385 m³ |
|
Number of slop tanks |
2 |
|
Pumps |
4x Cargo pumps each 500 m³/h |
|
Tank capacities |
Diesel oil: 99,04 t Freshwater: 474,12 t Fuel oil: 648,55 t Lube oil: 65,33 t Tank ballast: 6.982,88 t |
|
Number of tanks |
Ballast: 13 Fuel oil: 11 Lubricating oil: 8 Diesel oil: 5 Fresh water: 5 Waste water: 2 Chain: 2 |
|
Tank capacities |
Ballast: 7.416 m³ |
|
Anchor equipment |
Length: 577,00 m Diameter: 56 mm |
|
Lifting equipment |
1x Hose handling crane - SWL 10,0 t Manufacturer: Wuxi Jiangnan Marine Equipment Co Manufacturer: Jiangyin OYA Marine Machinery |
|
Crew size |
25 |
|
Manager |
Unicorn Shipping, a Division of Grindrod Shipping (Pty) Ltd. |
|
Registered owner |
Unicorn Caspian Pte. Ltd. |
|
Latest data adjustment |
22 May 2018 |
