Westerschelde 28 July 2016 |
|
Name |
MAERSK MIYAJIMA |
|
Type |
Oil product tanker |
|
IMO-number |
9590905 |
|
Call sign |
3FUP9 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
28.777 t registered Suez: 30.240,45 t |
|
DWT |
Summer: 48.020 t |
|
NT |
12.680 t registered Panama: 23.899,58 t Suez: 27.485,47 t |
|
Length |
179,90 m overall 172,00 m between perpendiculars |
|
Breadth |
32,20 m moulded |
|
Draught |
Max: 12,62 m |
|
Freeboard |
6.462 mm |
|
Depth |
19,05 m moulded |
|
Speed |
Max: 15,3 knots |
|
Built |
2011 |
|
Keel laid |
22/10/2010 |
|
Launch date |
26/03/2011 |
|
Date of completion |
01/09/2011 |
|
Builder |
Iwagi Zosen Co Ltd. |
|
Yard number |
S-Z288 |
|
Hull material |
High strength steel Ordinary strength steel |
|
Hull type |
Double hull |
|
Watertight bulkheads |
14 |
|
Main engine |
1x 6S50MC-C - 6 cylinder 500 x 2.000 mm combustion engine 9.480 kW at 127,0 rpm Manufacturer: Mitsui Engr. & Shipbuilding Co. Ltd. - Japan |
|
Propellers |
1 Manufacturer: Nakashima Propeller Co., Ltd. |
|
Boilers |
1x Auxiliary boiler - 8,0 bar 1x Exhaust gas boiler - 12,0 bat Manufacturer: Miura Co., Ltd. |
|
Generators |
3x Main diesel generatorsets each 720 kX Manufacturer: Nishishiba Electric Co., Ltd. |
|
Number of cargo tanks |
16 |
|
Cargo tank capacity 100% |
53.772,48 m³ |
|
Number of slop tanks |
3 |
|
Number of tanks |
Ballast: 14 Fuel oil: 9 Lubricating oil: 5 Fresh water: 3 Diesel oil: 3 Chain: 2 Waste water: 2 Sea water: 1 Sludge: 1 |
|
Tank capacities |
Diesel oil: 162,33 m³ Freshwater: 532,5 m³ Fuel oil: 2.296,01 m³ Lube oil: 83,55 m³ Tank Ballast: 20.831,19 m³ |
|
Lifting equipment |
1x Hose handling crane - SWL 10,0 t Manufacture: Kyoritsu Kikai Co., Ltd. 1x Provision crane - SWL 0,9 t 1x Provision crane - SWL 2,0 t Manufacture: Nantong Sekigahara Machinery Manufacturing Co., Ltd. |
|
Operator |
Anglo-Eastern Tanker Management (Hong Kong) Limited |
|
Registered owner |
Maxim Sunlight SA |
|
Latest data adjustment |
28 October 2018 |
