Westerschelde 23 March 2020 |
 |
 |
 |
||
| Antwerpen 26/04/19 | Antwerpen 26/04/19 | Westerschelde 16/04/16 | ||
|
Name |
STI CLAPHAM |
|
Type |
Chemical and oil product tanker - Handymax |
|
IMO-number |
9696577 |
|
Call sign |
V7DO7 |
|
Flag |
Marshall Islands |
|
Port of registry |
Majuro |
|
GT |
24.162 t Suez: 25.293,51 t |
|
DWT |
Summer: 38.734 t |
|
NT |
10.458 t |
|
Length |
183,60 m overall 176,00 m between perpendiculars |
|
Breadth |
27,40 m extreme |
|
Draught |
Max: 11,92 m |
|
Depth |
17,60 m |
|
Speed |
14,5 knots |
|
Built |
2014 |
|
Keel laid |
26/11/2013 |
|
Launch date |
19/08/2014 |
|
Date of completion |
27/11/2014 |
|
Builder |
Hyundai Mipo Dockyard Co., Ltd. Ulsan South Korea |
|
Yard number |
2478 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Number of desks |
1 |
|
Main engine |
1x HHI/MAN-B&W 6S50ME-B9 - 2 stroke 6 cylinder combustion engine 8.502 kW / 11.559 hp at 104,5 rpm |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Auxiliary boiler, oil/gas fired 1x Auxiliary boiler, composite Builder: Alfa Laval Aalborg A/S |
|
Generators |
3x Hyundai 6H21/32 main diesel generatorsets each 1.080 kW Builder: Hyundai Heavy Industries Co., Ltd. |
|
Emergency generator |
1x Doosan AD/L 086 diesel generatorset Builder: Doosan Infracore Co., Ltd. |
|
Bow thruster |
1x 1.070 kW |
|
Number of cargo tanks |
12 + 2 slop tanks |
|
Cargo tank capacity 100% |
43.511,6 m³ |
|
Pumps |
12x Framo SD 200 cargo pumps each 500 m³/h 2x Framo SD 125 cargo pumps |
|
Tank capacities |
Ballast: 19.390,7 m³ |
|
Anchor equipment |
Length: 632,50 m Diameter: 68 mm |
|
Lifting capacity |
1x Hose handling crane - SWL 10,0 t 1x Provision crane - SWL 4,0 t 1x Engine room crane - SWL 3,0 t |
|
Manager |
Zenith Gemi Isletmeciligi A.S. Poligon Cad., Buyaka 2 Sitesi, No:8, C Blok, Kat 18 34771, Umraniye, Istanbul Turkey |
|
Operator |
Scorpio Tankers Incorporated 99, Boulevard du Jardin Exotique Monaco, 98000 Monaco |
|
Registered owner |
STI Clapham Shipping Company Limited Majuro Marshall Islands |
|
Latest data adjustment |
11 January 2024 |
