Westerschelde 31 May 2019 |
 |
 |
 |
||
| Westerschelde 31/05/19 | Westerschelde 05/07/18 | Westerschelde 18/04/19 | ||
|
Name |
ATLANTIK MIRACLE |
|
Type |
Tank for oil and chemicals |
|
IMO-number |
9477490 |
|
Call sign |
9HPX9 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
GT |
7.315 t |
|
DWT |
Summer: 11.320,2 t |
|
NT |
3.589 t |
|
Length |
129,50 m overall 122,70 m between perpendiculars |
|
Breadth |
19,80 m |
|
Draught |
Max: 8,15 m |
|
Keel to mast end |
35,48 m |
|
Freeboard |
2.262 mm |
|
Depth |
10,40 m |
|
Speed |
Max: 14,0 knots Service: 13,0 knots Eco: 12,5 knots |
|
Built |
2008 |
|
Date of completion |
15/10/2008 |
|
Builder |
Selah Tersanesi Istanbul Turkey |
|
Yard number |
52 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Watertight compartments |
83 |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 9M32C - 4 stroke 9 cylinder 320 x 480 mm combustion engine 4.500 kW / 6.070 bhp at 600 rpm Builder: Caterpillar Motoren GmbH & Co. Kg, Kiel - Germany |
|
Propellers |
1x Screw propeller controllable pitch - aft at 120 rpm |
|
Boilers |
2x CHO PWT Prozess 81,00 m² - 10,0 bar 1x CHR PWT Prozess 68,80 m² - 10,0 bar |
|
Generators |
3x Main diesel generatorsets each 738 kVA - 590 kW - 842 hp |
|
Bow thruster |
1x 522 kW |
|
Number of cargo tanks |
14 + 2 slop tanks |
|
Total cap. of tanks 98% |
12.469,7 m³ |
|
Number of slop tanks |
2 |
|
Number of pumps |
12x Cargo pumps each 250 m³/h |
|
Tank capacities |
Fuel: 672,68 m³ |
|
Lifting equipment |
1x Gürdesan for cargo operations - SWL 5,0 t 1x Service crane - SWL 2,0 t |
|
Crew size |
19 |
|
ISM & commercial manager |
Atlantik Denizcilik Ticaret Hakkı Yeten Cad., Selenium Plaza, No:10/C, Kat: 11 Beşiktaş 34349 Istanbul Turkey |
|
Operator |
Compass Shipping & Trading Ltd. |
|
Registered owner |
Amikos Shipping Ltd. - Malta Care of Atlantik Denizcilik Ticaret ve Sanayi AS, Kat 11, Selenium Plaza, Hakki Yeten Caddesi 10C, Dikilitas Mah, Besiktas 34349 Istanbul Turkey |
|
Latest data adjustment |
15 March 2022 |
