Name |
LIV KNUTSEN |
|
Type |
Tanker for chemicals and oil products |
|
IMO-number |
9409273 |
|
Call sign |
9HA5042 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
Previous flags |
2009 - 2019 United Kingdom, Aberdeen - Call sign: 2CJU3 |
|
GRT |
11.889 t |
|
DWT |
Summer: 16.585 t |
|
NRT |
5.151 t |
|
Length |
144,18 m overall 133,80 m between perpendiculars |
|
Breadth |
23,04 m extreme |
|
Draught |
Max: 8,91 m |
|
Kel to mast end |
44,30 m |
|
Depth |
12,39 m |
|
Speed |
Max: 15,8 knots |
|
Built |
2009 |
|
Keel laid |
17/09/2008 |
|
Launch date |
26/12/2008 |
|
Date of completion |
11/08/2009 |
|
Builder |
Jiangnan Shipyard (Group) Co., Ltd. Shanghai China |
|
Yard number |
H2428 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x MAN-B&W 6L48/60B - 4 stroke 6 cylinder 480 x 600 mm combustion engine 6.120 kW / 8.321 at 514 rpm |
|
Propellers |
1x Controllable pitch propeller Diameter: 5.400 mm |
|
Boilers |
1x Auxiliary boiler, oil/gas fired 1x Auxiliary boiler, composite Builder: Aalborg Industries AS |
|
Shaft generator |
1x AVK 1.500 kW |
|
Generators |
2x Wärtsilä 4L20 main diesel generatorsets each 640 kW 1x Wärtsilä 6L20 main diesel generatorset 960 kW Builder: Wärtsilä Finland oy |
|
Emergency generator |
1x Diesel generatorset 100 kW |
|
Bow thruster |
1x Kamewa Ulstein 750 kW |
|
Number of cargo tanks |
12 + 2 slop tanks |
|
Cargo tank capacity |
19.553,3 m³ |
|
Number of pumps |
12x Framo cargo pumps each 300 m³/h |
|
Tank capacities |
HFO: 580 m³ Diesel oil: 74 m³ Fresh water: 502 m³ Ballast: 8.178,8 m³ |
|
Anchor equipment |
Length: 573,90 m Diameter: 58 mm |
|
Lifting equipment |
1x Crane - SWL 10,0 t 1x Crane - SWL 3,0 t |
|
Crew size |
25 |
|
ISM & commercial manager |
Knutsen OAS Shipping AS Smedasundet 40 N-5529 Haugesund Norway |
|
Registered owner |
Algoma Tankers Malta Ltd. 25/16 Vincenti Buildings Strait Street VLT 1432 Valletta Malta |
|
Previous owner |
Knutsen Produkt Tanker XII AS Care of Knutsen OAS Shipping AS, 5529 Haugesund - Norway |
|
Latest data adjustment |
04 August 2024 |
