Name
|
ATLANTIC CANYON
|
|
Type
|
Tanker for oil products and chemicals
|
|
IMO-number
|
9383974
|
|
Call sign
|
VRFG4
|
|
Flag
|
Hong Kong - China
|
|
Port of registry
|
Hong Kong
|
|
GT
|
23.342 t
|
|
DWT
|
Summer: 36.677 t
|
|
NT
|
9.529 t
|
|
Length
|
184,33 m overall
|
|
Breadth
|
27,40 m
|
|
Draught
|
Max: 11,32 m
|
|
Reg. dimensions L x B x D
|
177,46 x 27,40 x 17,20 m
|
|
Rule dimensions L x B x D
|
176,00 x 27,40 x 17,20 m
|
|
Freeboard
|
Summer: 5.914 mm
|
|
Depth
|
17,20 m
|
|
Speed
|
15,0 knots
|
|
Built
|
2009
|
|
Keel laid
|
18/02/2009
|
|
Launch date
|
15/04/2009
|
|
Date of completion
|
23/07/2009
|
|
Builder
|
Hyundai Mipo Dockyard Co., Ltd.
Ulsan
South Korea
|
|
Yard number
|
2099
|
|
Hull material
|
Steel
|
|
Hull type
|
Double hull
|
|
Watertight bulkheads
|
Transverse: 11
|
|
Continuous decks
|
1
|
|
Main engine
|
1x MAN-B&W/HHI 6S46MC-C - 2 stroke single acting 6 cylinder 460 x 1.932 mm combustion engine 7.860 kW at 129,0 rpm
Build: 02/2009
Builder: Hyundai Heavy Industries Co., Ltd., Ulsan - South Korea
|
|
Propellers
|
1x Fixed propeller
|
|
Boilers
|
1x Auxiliary water tube boiler 8,8 bar
Heating Surface: 191,8 m²
2x Economizer exhaust gas boiler - 11,7 bar
Heating Surface: 260 m²
Build: 03/2009
Builder: Kangrim Heavy Industrial Co., Ltd., Changwon - South Korea
|
|
Generators
|
3x Generatorsets each 912 kVA - 450 Volt
|
|
Number pf cargo tanks
|
16
|
|
Cargo tank capacity
|
42.335 m³
|
|
Slop tank capacity
|
1.046 m³
|
|
Pumps
|
16x Cargo pump each 500 m³/h
|
|
Tank capacities
|
Fuel oil: 1.133 m³
Fresh water: 242,7 m³
|
|
Crew size
|
25
|
|
Crew
|
21
|
|
Manager
|
CIDO Shipping HK Co Ltd.
Hong Kong
|
|
Technical manager
|
Executive Ship Management Pte Ltd.
10th Floor, Menara Hap Senh
1 & 3 Jalan P Ramlee
50250 Kuala Lumpur
Malaysia
|
|
Registered owner
|
Heroic Hydrus Inc.
c/o Hanjin Shipping Co., Ltd.
25 Gukjegeumyung-ro 2-gil Yeongdeungpo-gu
Seoul
South Korea
|
|
Latest data adjustment
|
01 October 2020
|
