Westerschelde 03 April 2019 |
 |
 |
|
| Westerschelde 03/04/19 | Westerschelde 28/04/19 | |
|
Name |
TRANS HOLM |
|
Previous names |
1999 - 2016 Bow Master |
|
Type |
Tanker for chemicals and oil products |
|
IMO-number |
9164718 |
|
Call sign |
9HA4434 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
Previous flags |
1999 - 2016 Republic of Singapore, Singapore City - Call sign: 9VWQ |
|
GT |
4.667 t |
|
DWT |
Summer: 6.046 t |
|
NT |
1.956 t |
|
Length |
103,60 m overall 97,40 m between perpendiculars |
|
Breadth |
16,63 m extreme |
|
Draught |
Max: 7,11 m |
|
Depth |
9,40 m |
|
Speed |
13,0 knots |
|
Built |
1999 |
|
Keel laid |
12/05/1998 |
|
Launch date |
21/07/1998 |
|
Date of completion |
07/01/1999 |
|
Builder |
Stocznia Szczecinska Nowa Sp. z o.o. Szczecin Poland |
|
Yard number |
B579/1 |
|
Hull material |
Steel |
|
Hull type |
Double bottom Double side |
|
Bulkheads |
Transverse: 6 |
|
Continuous decks |
1 |
|
Main engine |
1x Cegielski/MAN-B&W 6S35MC - 6 cylinder combustion engine 3.600 kW at 173,0 rpm |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
1x Auxiliary boiler, oil/gas fired 1x Auxiliary boiler, composite Builder: Aalborg Industries A/S |
|
Generators |
2x MAN-B&W 6L16/24 - 4 stroke 6 cylinder 160 x 240 mm diesel generatorsets each Mcr 600 kW |
|
Emergency generator |
1x MAN D2866E diesel generatorset |
|
Bow thruster |
1x 394 kW |
|
Number of pumps |
14x Cargo pumps each 200 m³/h |
|
Tank capacities |
Ballast: 2.374,1 m³ Bunker: 296 t |
|
Crew size |
16 |
|
Manager |
Stödig Ship Management AS |
|
Registered owner |
Kjemikalietank AS Care of Seatrans AS Wernersholmvegen 5 NO-5232 Paradis Norway |
|
Previous names & owners |
1999 - 2007 Bow Master - Odfjell Tankers (Asia) Pte Ltd. 2007 - 2016 Bow Master - Odfjell Asia II Pte Ltd. 2016 Trans Holm - Norfra Shipping AS |
|
Latest data adjustment |
22 July 2021 |
