Westerschelde 03 January 2016 |
 |
|
| Westerschelde 07/10/18 | |
|
Name |
NORDSTRAUM |
|
Previous names |
2012 Build as: Zhong Ding 3 2012 - 2015 Harbour Muran |
|
Type |
Chemical tanker |
|
IMO-number |
9523548 |
|
Call sign |
LAWE7 |
|
Flag |
Norway |
|
Port of registry |
Bergen |
|
Previous flags |
Denmark, København - Call sign: OUZF2 |
|
GT |
6.768 t |
|
DWT |
8.363 t |
|
NT |
2.122 t |
|
Length |
118,95 m overall 144,61 m registered |
|
Breadth |
18,50 m registered |
|
Draught |
7,50 m |
|
Keel to mast end |
33,79 m |
|
Depth |
11,20 m moulded |
|
Speed |
14,5 knots |
|
Built |
2012 |
|
Keel laid |
12/02/2010 |
|
Launch date |
16/05/2011 |
|
Date of completion |
30/05/2012 |
|
Builder |
AVIC Dingheng Shipbuilding Co., Ltd. Ship Industry District 1 Zhonghang Road Jiangdu Economic Development Jiangdu, Jiangsu People's Republic of China |
|
Yard number |
DH5201-5 |
|
Hull material |
Shipbuilding steel (standard) Higher tensile steel |
|
Hull type |
Double hull Double bottom, continuous from peak to peak bulkhead |
|
Main engine |
1x MAN 9L32/44CR - 4 stroke 9 cylinder 320 x 440 mm combustion engine 5.040 kW / 6.852 bhp at 750 rpm Year of manufacture: 2010 Manufacturer: MAN Diesel & Turbo SE Stadtbachstr. 1 86153 Augsburg Federal Republic of Germany |
|
Propellers |
1x Controllable pitch propeller - aft at 142 rpm |
|
Boilers |
1x Thermal oil heater, exhaust gas heated - 10,0 bar Heating surface: 133,3 m² 2x Thermal oil heater, oil fired - 10,0 bar Heating surface: 123,0 m² Year of manufacture: 2010 Manufacturer: Göteborgs Energy Systems AB Angpannegatan 15A 417 05 Göteborg Sweden |
|
Electric installations |
3x Plants each 440 V - 737 kVA 1x Plant 440 V - 1.500 kVA 1x Plant 440 V - 135 kVA 1x Plant 12 V - 12 Ah 1x Plant 12 V - 200 Ah 1x Plant 12 V - 200 Ah 3x Plants each 12 V - 600 Ah |
|
Shaft generator |
1x 1.500 kVA |
|
Generators |
3x Main diesel generatorsets each 737 kVA |
|
Emergency generator |
1x Diesel generatorset 135 kVA |
|
Batteries |
3x Batteries for automation each 600 Ah 1x Battery for UPS radio 200 Ah 1x Battery for start emergency engine 200 Ah 1x Battery for diesel control 12 Ah |
|
Compressed air receivers |
2x Receivers each 1.000 litres - 30,0 bar 1x Receiver 1.500 litres - 11,0 bar |
|
Bow thruster |
1x Transverse thruster 500 kW, forward |
|
Number of pumps |
14 + 2 slop tanks |
|
Segregations |
16 |
|
Cargo capacity 98% |
Liquid: 9.354,10 m³ |
|
Number of pumps |
14x Cargo pumps each 210 m³/h |
|
Anchor equipment |
3x Anchors weight each 3.780 kg Chain length: 522,50 m Diameter: 48 mm |
|
Crew size |
18 |
|
ISM & commercial manager |
Utkilen AS Strandgaten 197 5004 Bergen Norway |
|
Previous managers |
Nordic Tankers Marine A/S, Copenhagen - Kingdom of Denmark |
|
Registered owner |
Utkilen Shipping AS Care of Utkilen AS Strandgaten 197 5004 Bergen Norway |
|
Latest data adjustment |
11 February 2024 |
