Siskin - IMO 9563201

Name

SISKIN

Previous names

2011 - 2013 DMS Siskin

Type

Tug / Pusher

Damen Shoalbuster 2709

Basic functions

Towing, Anchor handling, Dredge support, Supply, Survey, Windfarm support

IMO-number

9563201

Call sign

PCLJ

Flag

The Netherlands

Port of registry

Zwijndrecht

Previous flags

02/2017 - 08/2018 Australia, Darwin - Call sign: VNZ2331

GT

221 t

DWT

200 t

NT

66 t

Length

27,02 m overall

23,84 m between perpenciulars

Breadth

9,10 m

Draught

Summer: 2,60 m

Speed

11,9 knots

Built

2011

Launch date

27/08/2009

Date of completion

29/05/2011

Delivery date

06/2011

Builder

Damen Shipyards Hardinxveld

The Netherlands

Yard number

571624

Hull material

Steel

Watertight compartments

4

Continuous decks

1

Main engine

2x Caterpillar 3512B TA/A - 4 stroke 12 cylinder 170 x 190 mm combustion engines total 2.238 kW / 3.040 hp at 1.600 rpm

Builder: Caterpillar, Mossville - USA

Gearbox

2x Reintjes WAF 665 - Reduction 5.95:1

Propellers

2x Promarin fixed pitch propellers - aft at 269 rpm

Diameter: 2.100 mm

Generators

2x Caterpillar C-4.4 TA diesel generatorsets each 86,3 kVA - 69 kW - 117 hp / 230/400 Volt 50 Hz

Hydraulic set

1x Caterpillar C-09 TA

Compressors

1x ABAC 150 ltr/min

1x Alup SCK 9-8 @ 1.200 ltr/min

Bow thruster

1x 200 bhp

Bollard pull

40,0 t

Deck layout

• Anchors: 2 x 225 kg Pool 110,00 m shortlink 22 mm chain

• Chain: 192,50 m shortlink 17,5 mm chain

• Anchor winch: Ridderinkhof , hydraulic

• Deck crane: Heila HLRM 140-4SL, 10 ton @ 12,25 m

• Towing winch: Ridderinkhof 75 ton / min Holding 100 ton

• Anchor handling: Ridderinkhof 40 ton, capacity: 700 meter for towing 400 meter

• Towing pins: 3x Hydraulic tow / anchorhandling pins

• Tugger winch: Brevini, 8 ton (m) @ 9,00m/min

• Maximum deckload: 10 ton /m²

• Free deck space: 47 m²

Tank capacities

Fuel oil : 122,00 m³

Fresh water : 30,10 m³

Sewage : 2,20 m³

Dirty oil : 4,30 m³

Lub, oil : 3,90 m³

Hydraulic oil : 1,60 m³

Bilge Water : 4,30 m³

Accommodation

Heated and air-conditioned living spaces for seven persons, consisting of a captain’s cabin , a C.E. cabin , one single crew cabin, two double crew cabins, a galley and sanitary facilities

Manager

• According GMDSS: Area A3

• Searchlights: 2x Pesch 1000 W

• Magnetic compass: 1x Cassens & Plath Reflecta 1

• Gyro compass: 1x Anschuetz STD 22 Compact

• Radar system: 1x Furuno FR-2117B

• AIS: 1x Furuno FA 150

• D-GPS: 1x Furuno GP-150

• Plotter: 1x Tresco ECDIS

• Gyrocompass: 1x Raytheon Anschutz STD 22

• Autopilot: 1x RH Sea/river pilot 75

• Echosounder: 1x Furuno FE 700

• Handheld VHF: 2x Jotron TRON TR20

• Watch alarm: 1x Marble 421

• VHF radio telephone: 2x sailor 5022 with DSC + 1x sailor 4800

• Navtex: 1x Furuno NX 700

• SSB/DSC: 1x Furuno, type FS-1570

• Communication: 2x Inmarsat C, Satellite telephone, GSM

• V-SAT: 1x Intellian V80G

• CCTV: 1x Orlaco

Owner

Herman Sr. BV

Ebweg 56

2991 LT Barendrecht

The Netherlands

Previous names & owners

2011 - 2013 DMS Siskin - Damen Marine Services BV in Gorinchem - The Natherlands

Latest data adjustment

16 December 2022
