| Westerschelde 08 May 2018 |
|
Name |
HIGHLAND MONARCH |
|
Type |
Platform supply vessel |
|
IMO-number |
9249453 |
|
Call sign |
VQQZ8 |
|
Flag |
United Kingdom |
|
Port of registry |
London |
|
GT |
1.992 t |
|
DWT |
2.986 t |
|
NT |
926 t |
|
Displacement |
4.553 t |
|
Light ship |
1.582,63 t |
|
Length |
67,00 m overall 61,80 m between perpendiculars |
|
Breadth |
16,03 m extreme |
|
Draught |
Summer: 5,91 m |
|
Keel to mast end |
28,00 m |
|
Freeboard |
1.101 mm |
|
Depth |
7,00 m moulded |
|
Speed |
Max: 12,0 knots |
|
Built |
2003 |
|
Keel laid |
23/04/2002 |
|
Launch date |
10/02/2003 |
|
Date of completion |
03/07/2003 |
|
Builder casco |
Aker Tulcea SA Tulcea Romania Yard number: 296 |
|
Builder completion |
Vard Group AS Avd Brattvaag Yard number: 96 |
|
Hull material |
Steel |
|
Bulkheads |
Transverse: 4 Longitudinal: 2 |
|
Continuous decks |
1 |
|
Main engine |
2x Bergen KRMB-9 - 4 stroke single acting 9 cylinder 250 x 300 mm combustion engines total 4.010 kW / 5.438 hp at 825 rpm Build: 11/02/2003 Builder: Rollys Royce Marine AS, Bergen - Norway |
|
Propellers |
2x Controllable pitch propeller |
|
Shaft generator |
2x 1.280 kW - 450 Volt 60 Hz |
|
Generators |
2x Caterpillar 3406 main diesel generatorsets each 277 kW - 450 Volt 60 Hz |
|
Emergency generator |
1x Cummins 4B(T)3.9 diesel generatorset |
|
Thrusters |
2x Thruster each 582 kW, forward 1x Thruster each 582 kW, stern |
|
Tank capacities |
Ballast: 503 m³ |
|
Anchor equipment |
Length: 467,50 m Diameter: 38 mm |
|
Crew size |
21 |
|
Manager |
GulfMark UK Ltd. Aberdeen United Kingdom |
|
Registered owner |
GulfMark UK Ltd. Aberdeen United Kingdom |
|
Renamed |
06/2020 - 09/2020 Highland Monarch Saint Vincent an the Grenadines, Knigstown - Call sign: J8B5984 2021 Offshore Monarch India, Mumbai - Call sign: VTFY Owner & manager: RAJ Shipping Agencies Ltd., Mumbai - India |
|
Latest data adjustment |
30 January 2023 |
