Name |
FAIRPLAY-23 |
|
Type |
ASD Schottel Tug fully equipped for harbour assistance, escorting, terminal operation, coastal towage & salvage |
|
IMO-number |
9148776 |
|
Call sign |
SNOA |
|
Flag |
Poland |
|
Port of registry |
Szczecin |
|
Previous flag |
1998 - 2019 Antigua & Barbuda, St. John's - Call sign: V2GP |
|
GT |
496 t |
|
DWT |
317 t |
|
NT |
148 t |
|
Length |
34,75 m overall 32,14 m registered |
|
Breadth |
10,80 m overall |
|
Draft |
Min.: 4,60 m Max.: 5,00 m |
|
Depth |
5,70 m moulded |
|
Speed |
13,5 knots |
|
Built |
1998 |
|
Keel laid |
13/02/1997 |
|
Launch date |
13/11/1997 |
|
Date of completion |
01/06/1998 |
|
Builder |
Construcciones Navales Santodomingo, S.A. Avda. Beiramar, 131 36208 Vigo (Pontevedra) Spain |
|
Yard number |
614 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Partly double bottom (e.g. interrupted in way of machinery space) |
|
Watertight bulkheads |
4 |
|
Continuous decks |
1 |
|
Main engine |
2x Deutz SBV8M628 - 4 stroke 8 cylinder 240 x 280 mm combustion engines each 1.646 kW at 1.000 rpm Total 3292 kW / 4.500 bhp Year of manufacture: 1997 Manufacturer: Deutz MWM Motoren-Werke Mannheim AG Mannheim Federal Republic of Germany |
|
Propeller |
2x Schottel rudder propeller SRP 1212 in Kort nozzles at 300 rpm 4 Blades - Diameter: 2.300 mm |
|
Electric installations |
1x Plant 380/220 V - 130 kVA |
|
Generators |
2x MAN D2866 E - Diesel engines each 97 kW at 1.500 rpm connected generators each 130 kVA Built: 1997 |
|
Compressed air receivers |
2x Receivers each 250 litres - 30,0 bar |
|
Bow thruster |
1x Schottel bow thruster STT 110 LK - 200 kW |
|
Towing equipment front |
1x Ulstein Brattvaag SL-50 Single Drum Wire length: 110 m Wire diameter: 46 mm Brake holding power: 128 t |
|
Towing equipment aft |
1x Ulstein Brattvaag SL-50 Double Drum Wire length: 1.400 m & 110 m Wire diameter: 46 mm & 46 mm Brake holding power: 128 t |
|
Tow pins |
2 |
|
Towing hook |
Seebeck 55 t |
|
Bollard pull |
52 t |
|
FiFi Pump |
1x Deutz TBD 616 V 8 - 8 cylinder 132 x 160 mm diesel engine 407 kW at 1.800 rpm Built: 1997 |
|
Tank capacities |
Fuel oil: 220 m³ Water ballast: 110 m³ |
|
Anchor equipment |
3x Anchors weight each 1.020 kg Chain length: 357,50 m |
|
Lifting equipment |
1x Crane - SWL 1,0 t at 3,5 m |
|
Navigation & Communications |
2x Radars 1x AIS 1x Magnetic Compass 1x Gyro Compass 1x Echo Sounder 1x Autopilot 2x VHF 1x SSB Radio 1x GPS 1x Navtex |
|
Manager |
Fairplay Towage Polska Sp. z.o.o. sp.k. Plac Rodła 9 70-419 Szczecin Poland |
|
Owner |
Fairplay Towage Polska Sp. z.o.o. sp.k. Plac Rodła 9 70-419 Szczecin Poland |
|
Previous owner |
Fairplay Schleppdampfschiffs Reederei Richard Borchard GmbH, 20457 Hamburg - Federal Republic of Germany |
|
Latest data adjustment |
26 February 2023 |
