Name |
STEVNS ARCTIC |
|
Type |
Tug |
|
IMO-number |
9261607 |
|
Call sign |
OWXV2 |
|
Flag |
Denmark |
|
Port of registry |
Svendborg |
|
GT |
512 t |
|
NT |
153 t |
|
Length |
33,50 m overall 31,36 m between perpendiculars |
|
Breadth |
11,60 m moulded |
|
Draft |
5,20 m moulded 5,65 m extreme |
|
Depth |
5,40 m moulded |
|
Speed |
Max.: 13,5 knots |
|
Built |
2005 |
|
Date of completion |
06.2005 |
|
Builder |
Irving Shipbuilding Inc. |
|
Main engine |
2x MaK 6M 25 diesel engines each developing 1.850 kW |
|
Propeller |
2x Rolls Royce 225CP Azimuth propellers |
|
Generators |
2x Volvo diesel generatorsets each 200 kW 1x Volvo diesel generatorset 100 kW |
|
Bow thruster |
KaMeWa - 260 kW CP |
|
Bollard pull |
65 t |
|
Towing winch |
Max. brake force: 160 t |
|
Hawser winch |
Max. braking force: 160 t |
|
Towing wire |
Length: 1.000 m Diameter: 52 mm |
|
Electric tugger winch |
10 t |
|
Electric capstan |
10 t |
|
Fire fighting |
2x Water monitors each 350 m³/h |
|
Lifting equipment |
1x Hydraulic crane - SWL 10 t at 3 m arm |
|
Accommodation |
For 8 persons |
|
Manager |
Nordane Shipping |
|
Operator |
Stevns Charter & Towage A/S 5700 Svendborg |
|
Owner |
Nordane Shipping |
