| Antwerpen 15 November 2013 |
 |
 |
 |
||
| Antwerpen 04/03/13 | Antwerpen 14/08/17 | Antwerpen 26/04/19 | ||
|
Name |
TUG 41 |
|
Type |
Tug boat |
|
IMO-number |
9602100 |
|
ENI-number |
06105320 |
|
Call sign |
ORQL |
|
Flag |
Belgium |
|
Port of registry |
Antwerpen |
|
GT |
430 t |
|
DWT |
200 t |
|
NT |
129 t |
|
Length |
29,50 m overall 27,50 m between perpendiculars |
|
Breadth |
12,55 m overall |
|
Draught |
4,54 m |
|
Freeboard |
4.500 mm |
|
Depth |
4,50 m |
|
Speed |
13,0 knots |
|
Built |
2012 |
|
Date of completion |
04.09.2012 |
|
Builder |
Union Naval Valencia (Boluda Shipyards) |
|
Yard number |
489 |
|
Hull material |
Mild steel |
|
Main engine |
2x ABC 12VDCZ - 4 stroke 12 cylinder 256 x 310 mm diesel engines - each 3.590 hp total 5.280 kW / 7.174 hp at 1.000 rpm Builder: Anglo Belgian Corporation N.V. Wiedauwkaai 43 |
|
Propelling system |
2x Voith-Schneider / Cycloidal prop controllable pitch |
|
Generators |
2x Diesel generatorsets each 249 kVA - 199 kW - 270 hp |
|
Fuel capacity |
142,7 m³ |
|
Owner |
A.G. Gemeentelijk Havenbedrijf 2000 Antwerpen Belgium |
|
Registered owner |
Antwerp Port Authority |
|
Last update |
02.04.2013 |
