Mustang - IMO 9555383

Westerschelde 08 August 2016

Name

MUSTANG

Type

AHT - Anchor Handling Tug

IMO-number

9555383

Call sign

5BZD2

Flag

Cyprus

Port of registry

Limassol

Previous flags

2009 - 2013 The Netherlands, Amsterdam - Call sign: PBRI

2013 - 2017 Russia, Arkhangelsk - Call sign: UEVG

2017 - 2020 Cyprus, Limassol - Call sign: 5CTB

2020 - 2021 Russia, Saint Petersburg - Call sign: UBNU5

GT

332 t

DWT

Summer: 217 t

NT

99 t

Length

30,50 m overall

27,76 m between perpendiculars

Breadth

10,50 m

Draught

3,90 m

Freeboard

333 mm

Depth

4,14 m

Speed

13,5 knots free running

Built

2009

Launch date

27/02/2009

Date of completion

03/04/2009

Builder

Scheepswerf Gebroeders Kooiman

Zwijndrecht

The Netherlands

Yard number

183

Hull material

Steel

Continuous decks

1

Main engines

2x Mitsubishi S12 U MPTK - 4 stroke 12 cylinder 240 x 260 mm combustion engine output each 2238 kW / 3.041 bhp at 1.100 rpm

Total 4.476 kW / 6.082 bhp

Builder: Mitsubishi, Sagamihara - Japan

Gearbox

2x ZF Masson type W 20500 1/5 red

Propulsion

2x Screw propeller solid in short nozzles at 240 rpm

5 Blades - Diameter: 2.800 rpm

Generators

2x Mitsubishi 6D16T diesel generatorsets each 120 kVA - 96 kW - 144 hp

Bow thruster

1x 240 kW

Bollard pull

83,1 t

Towing equipment

• Anchor Handling/Towing winch: Kraaieveld: Main drum: 1000 m 58 mm - 2nd drum: 700 m 58 mm

• Towing pins: Karmoy fork and towing pins

• Push bow: 2x 500 mm

• Stern roller: 8.500 x 1.800

• Tugger winch pull: 8500 kn wire 18 mm 40,00 m

Deck area

100 m²

Deck load

7,0 t/m²

Hydraulic set

1x Mitsubishi type S A3 MPTK - 600 hp

Transfer pumps

Water and fuel - 2 pump 50 m³/h each

Bunker capacities

Fuel oil: 223 m³

Fresh water: 18 m³

Lub oil: 3,6 m³

Hydraulic oil: 1,5 m³

Sewage: 4,8 m³

Lifting equipment

1x Deck crane HLRM 200-4SL - SWL 20,0 t on starboard side

Accommodation

8 Persons

Nautical equipment

• GMDSS Epirb: Tron-40 S tronsart

• GMDSS VHF: 2x handset

• Deck handset: 3x Entel submersible

• VHF Wheelhouse: 6x VHF Sailor, 2 x with DSC

• Radar System: 2x Furuno 2117 with Arpa

• SSB Furuno: FS 2570 250 watt pep

• Electronic Chart System: 2x Furuno type FEA 2107

• System: 2x Transas Navisallor

• Autopilot: RZ Seapilot 75

• Inmarsat C: 2x Furuno Falcon 15

• Echo Sounder: Furuno FE 700

• DGPC: 2x Furuno GP 150 with SSAS facility

• AIS: Furuno FA 150

• Gyrocompass: Tokimec ES 150

• Nav. Echo Sounder: Furuno NX 700 + 701

• Doppler Log: Furuno DS 80

• Airco: All cabins

• Telephone/Fax/E-mail: GMS and Satellite

Manager

DMC - Dutch Marine Contractors B.V.

Silodam 139

1013 AS Amsterdam

The Netherlands

ISM manager

Acheon Akti Navigation Company Limited

3 Thalia Street

3rd Floor, Office 303

3011 Limassol

Cyprus

Registered owner

IPPO Martime Ltd.

Cyprus

Latest data adjustment

17 August 2023
