Westerschelde 10 April 2018 |
 |
 |
 |
 |
|||
| Westerschelde 01/04/17 | Terneuzen 02/08/17 | Terneuzen 02/08/17 | Westerschelde 13/04/18 | |||
|
Name |
MULTRATUG 13 |
|
Previous names |
1993 - 01/2000 Nathalie Letzer 2000 - 2015 Zelzate |
|
Type |
Tug - Coastal area |
|
IMO-number |
9034999 |
|
Call sign |
PDCD |
|
Flag |
The Netherlands |
|
Port of registry |
Terneuzen |
|
Previous flags |
Belgium, Antwerpen - Call sign: ORLE |
|
GT |
249 t |
|
DWT |
Summer: 184 |
|
NT |
74 t |
|
Length |
31,99 m overall 27,28 m between perpendiculars |
|
Breadth |
9,04 m extreme 8,70 m moulded |
|
Draught |
3,95 m |
|
Depth |
4,67 m |
|
Speed |
Max.: 13,5 knots |
|
Built |
1993 |
|
Keel laid |
07/10/1992 |
|
Date of completion |
23/04/1993 |
|
Builder |
Scheepswerf van Rupelmonde (St Pieter) Rupelmonde Belgium |
|
Yard number |
471 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Continuous decks |
1 |
|
Main engine |
1x ABC 8MDZC-800-173 (K) - 4 stroke 8 cylinder combustion engine 1.472 kW / 1.998 at 800 rpm Builder: Anglo Belgian Corporation N.V. Wiedauwkaai 43 9000 Gent Belgium |
|
Gearbox |
Reintjes ZWAV 2650 reduction gearbox |
|
Propellers |
1x Fixed pitch propeller - 4 blades - diameter 2.700 mm |
|
Propulsion |
Steerable Kort Nozzle |
|
Generators |
2x Scania DS11 60M diesel engines each 200 kW continuous rating connected with Van Kaick generator resulting in a total power output of each 300 kVA - 3x 380 Volt - 50 Hz |
|
Bow thruster |
1x Guascor type F 240 TA-SP diesel engine driving a full azimuth retractable AQUAMASTER type UL 601/3500 - 2.000 kW / 2.719 bhp |
|
Bollard pull |
39 t |
|
Deck lay-out |
Anchor winch: Brusselle 6,4 t at 18,00 m/min Type: ALHS 30 Chain: U2 24 mm Towing/Breidelwinch: Brusselle 5 t at 50,00 m/min till 18 t at 13,40 m/min Brake capacity : 70 t Type: HSL 70/21-2/1 |
|
Tank capacities |
Fuel oil: 72,08 m³ Fresh water: 18,692 m³ Lubrication oil: 4,266 m³ Foam: 1,47 m³ |
|
Accommodation |
4x 2-Men cabins 1x Mess room 1x Galley |
|
Owner |
Multraship Towage & Salvage Scheldekade 48 4531 EH Terneuzen The Netherlands |
|
Previous owners |
1993 - 2015 N.V. Unie van Redding- en Sleepdienst, taliëlei 3, 2000 Antwerpen - Belgium |
|
Latest data adjustment |
27 February 2023 |
