Name |
ERACLEA |
|
Type |
AHTS - Anchor handling tug supply Supply vessel tug equipped for salvage services |
|
IMO-number |
9499656 |
|
Call sign |
IITX2 |
|
Flag |
Italy |
|
Port of registry |
Napoli |
|
GT |
1.397 t |
|
DWT |
Summer: 1.268 t |
|
NT |
419 t |
|
Length |
50,00 m overall 43,23 m between perpendiculars |
|
Breadth |
15,50 m extreme |
|
Draught |
Max: 5,68 m |
|
Freeboard |
865 mm |
|
Depth |
6,55 m |
|
Speed |
Service: 12,0 knots Max: 13,0 knots |
|
Built |
2010 |
|
Keel laid |
09/06/2009 |
|
Launch date |
14/11/2009 |
|
Date of completion |
01/06/2010 |
|
Builder |
Rosetti Marino S.P.A. - Shipyard Ravenna Italy |
|
Yard number |
C100 |
|
Watertight compartments |
5 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Number of decks |
1 |
|
Main engine |
2x Wärtsilä 6L32B3 - 4 stroke single acting 6 cylinder 320 x 400 mm combustion engines each Mcr 3.000 kW / 4.079 hp at 750 rpm Total: 6.000 kW / 8.152 hp Builder: Wärtsilä Finland Oy, Turku - Finland |
|
Propellers |
2x Ulstein controllable pitch propellers Diameter: 3.200 mm - 4 blades |
|
Boilers |
2x Thermal oil heater, oil fired 2x Thermal oil heater, exhaust heated |
|
Shaft generator |
2x Marelli MJR 400 LB4 each 1.250 kVA / 1.000 kW - 440 Volt 60 Hz |
|
Generators |
3x Volvo Penta D9AMG - 4 stroke 6 cylinder 120 x 138 mm diesel engines each Mcr 265 kW connected with generators each 215 kW / 440 Volt 60 Hz |
|
Bollard pull |
120 t |
|
Tank capacities |
Ballast: 212,4 m³ HFO: 1.041 t MGO: 168,3 t |
|
Anchor equipment |
Length: 440,00 m Diameter: 32 mm |
|
Accommodation |
Total 18 comfortable berths fully air conditioned |
|
Radio and navigation equipment |
2x Radars JRC (banda X, banda M) Radio station GMDSS A3 2x Gyro compass 2x GPS system 2x Inmarsat system C 1x Echo sounder Navtex Mini M TLF Fax Telex Autopilot Fleet 77 GSM TLF Joystick VSAT |
|
ISM manager |
Augustea Technoservices Ltd. Vault 5-6, Upper Floor - Pinto Wharf FRN1913, Floriana Malta |
|
Registered owner |
Augustea Ship Management S.R.L. Viale Antonio Gramsci, 5 80122 Naples Italy |
|
Latest data adjustment |
28 December 2022 |
