Westerschelde 18 July 2019 |
|
Name |
RCC ASIA |
|
Previous names |
2009 - 2019 CSCC Asia |
|
Type |
Roll-On/Roll-Off carrier PCTC - Pure Car and Truck Carrier |
|
IMO-number |
9391581 |
|
Call sign |
C6WY8 |
|
Flag |
Bahamas |
|
Port of registry |
Nassau |
|
GT |
57.692 t |
|
DWT |
Summer: 21.037 t |
|
NT |
21.116 t |
|
Length |
199,98 m overall 188,18 m between perpendiculars |
|
Breadth |
32,26 m |
|
Draught |
Summer: 10,00 m |
|
Air draft |
45,64 m |
|
Depth |
19,98 m |
|
Speed |
Max: 20,1 knots |
|
Built |
2009 |
|
Keel laid |
06/12/2007 |
|
Launch date |
07/02/2009 |
|
Date of completion |
24/03/2009 |
|
Builder |
Stocznia Gdynia S.A. Gdynia Poland |
|
Yard number |
8168/24 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Bulkheads |
Transverse: 3 |
|
Number of decks |
14 |
|
Main engine |
1x H. Cegielski/Wärtsilä NSD 7RTA 62U - 7 cylinder combustion engine 15.540 kW at 113;0 rpm |
|
Propellers |
1x Mono-block fixed pitch propeller |
|
Boilers |
1x Auxiliary boiler, oil/gas fired Mission OS Manufacturer: Aalborg Industries A/S 1x Auxiliary boiler, exhaust gas heated AV-7 |
|
Generators |
3x MAN-B&W 7L28/32H main diesel generatorsets |
|
Emergency generator |
1x MAN D2866 LXE20 diesel generatorset |
|
Bow thruster |
1x Brunvoll ype FU 80 LTC 2250 - 1.300 kW |
|
RO-RO Ramp |
1x Starboard: 25,00 x 7, 00 x 22 t 1x Starboard aft: 38,00 x 7,00 x 150 t |
|
Number of cars |
6.658 |
|
Car deck areas |
Total: 54.900 m² Hoistable: 17.000 m² |
|
Tank capacities |
Ballast: 7.773,93 m³ Fuel oil: 3.350 m³ Diesel oil: 130 m³ Lub oil: 150 m³ Potable water: 260 m³ |
|
Anchor equipment |
Length: 660,00 m Diameter: 78 mm |
|
Lifting equipment |
1x Crane - SWL 5,0 t |
|
Crew size |
29 |
|
Manager |
Stamco Ship Management Co. Ltd. 21 Akti Miaouli Piraeus 185 35 Greece |
|
Operator |
Ray Car Carriers Ltd. Ilse of Man United Kingdom |
|
Registered owner |
Asia Maritime Ltd. Shanghai China |
|
Latest data adjustment |
02 January 2021 |
