| Westerschelde 30 May 2015 |
 |
|
| Westerschelde 31/07/15 | |
|
Name |
DREAM BEAUTY |
|
Type |
Roll-On/Roll-Off carrier PCC - Pure Car Carrier |
|
IMO-number |
9303168 |
|
Call sign |
3EFF2 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
41.662 t |
|
DWT |
15.119 t |
|
NT |
12.498 t |
|
Length |
186,00 m overall |
|
Breadth |
28,20 m |
|
Draught |
Summer: 8,52 m |
|
Reg. dimensions L x B x D |
181,03 x 28,20 x 18,95 m |
|
Rule dimensions L x B x D |
181,00 x 28,20 x 29,43 m |
|
Freeboard |
Summer: 3.964 mm |
|
Speed |
Max: 20,0 knots |
|
Built |
2006 |
|
Keel laid |
11/11/2004 |
|
Launch date |
27/02/2006 |
|
Date of completion |
02/06/2006 |
|
Builder |
Shin Kurushima Onishi Shipyard Imabari Japan |
|
Yard number |
5328 |
|
Hull material |
Steel |
|
Watertight bulkheads |
Transverse: 5 |
|
Main engine |
1x MAN-B&W 8S50MC MkVI - 2 stroke single acting 8 cylinder 500 x 1.910 mm combustion engine 11.440 kW / 15.560 hp at 127,0 rpm Build: 01/08/2005 Manufacturer: Mitsui E & S Machinery Co., Ltd. Tamano Works - Japan |
|
Propellers |
1 |
|
Boilers |
1x Auxiliary Boiler STB - 6,9 kg/cm² Heating Surface: 29,3 m² 1x Auxiliary Boiler EGE - 10,9 kg/cm² Heating Surface: 171,2 m² Build: 01/10/2005 |
|
Generators |
3x Main diesel generatorsets each 1.000 kVA / 450 Volt |
|
Number of decks |
9 |
|
Number of cars |
3.494 |
|
Tank capacities |
Fuel oil: 2.493,4 m³ Fresh water: 403,8 m³ Water ballast: 7.604,6 m³ |
|
Commercial manager |
Cido Shipping Co., Ltd 20th Floor, World-Wide House 19 Des Voeux Road Central Hong Kong |
|
ISM manager |
Cido Shipping(Korea) Co., Ltd. 3/4F, 874-14, Jeonpo 2- dong Busanjin-gu, Busan, 614-780 South Korea |
|
Registered owner |
Dynamic Leader Shipping SA c/o Cido Shipping (HK) Co Ltd, 20th Floor, World Wide House 19, Des Voeux Road Central Hong Kong |
|
Latest data adjustment |
04 October 2023 |
