Name |
DREAM DIAMOND |
|
Type |
Roll-On/Roll-Off vessel - Vehicles Carrier PCC - Pure Car Carrier |
|
IMO-number |
9325788 |
|
Call sign |
3EHY5 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
41.662 |
|
DWT |
Summer: 15.069 t |
|
NT |
12.498 |
|
Length |
186,00 m |
|
Breadth |
28,20 m |
|
Draught |
Summer: 8,52 m |
|
Reg. dimensions L x B x D |
181,03 x 28,20 x 18,95 m |
|
Rule dimensions L x B x D |
181,00 x 28,20 x 29,43 m |
|
Freeboard |
Summer: 3.964 mm |
|
Depth |
18,95 m |
|
Speed |
19,2 knots |
|
Built |
2007 |
|
Keel laid |
11/11/2004 |
|
Launch date |
07/10/2006 |
|
Date of completion |
20/01/2007 |
|
Builder |
Shin Kurushima Onishi Shipyard Co., Ltd. Imabari Japan |
|
Yard number |
5347 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Watertight bulkheads |
5 |
|
Main engine |
1x Mitsui/MAN-B&W 8S50MC - 2 stroke single acting 8 cylinder 500 x 1.910 mm combustion engine 11.440 kW / 15.499 hp at 127,0 rpm Build: 01/04/2006 Builder: Mitsui Engineering & Shipbuilding Co.,Ltd., Tamano - Japan |
|
Propellers |
1 |
|
Boilers |
1x Auxiliary Boiler STB - 6,9 kg/cm² Heating surface: 29,3 m² 1x Economizer EGE - 10,9 kg/cm² Heating surface: 171,2 m² Build: 01/04/2006 Builder: Tortoise Engineering Co., Ltd., Ehime - Japan |
|
Generators |
4x Main diesel generatorsets each 1.000 kVA - 450 Volt |
|
Bow thruster |
1x 930 kW |
|
Number of decks |
9 |
|
Car capacity |
4.113 |
|
Car deck area |
36.800 m² |
|
Liftable decks |
6 |
|
Stern ramp |
Max door width: 8,00 m Max door height: 5,30 m Max deck height: 5,10 m Capacity: 100 t |
|
Side ramp |
Max door width: 6,50 m Max door height: 6,00 Capacity: 35 t |
|
Tank capacities |
Fuel oil: 2.493,40 m³ Fresh water: 403,80 m³ Water ballast: 7.604,60 m³ |
|
Commercial manager |
Cido Shipping (H.K.) Co., Ltd. 20th Floor, World Wide House, 19, Des Voeux Road Central Hong Kong - China |
|
ISM manager |
Cido Shipping Korea Co. Ltd. 3rd & 4th Floors, 798, Jungang-daero, Busanjin-gu Busan South Korea |
|
Owner |
Dynamic Jumping Marine S.A. Care of Cido Shipping (HK) Co Ltd. 20th Floor, World Wide House, 19, Des Voeux Road Central Hong Kong - China |
|
Latest data adjustment |
03 April 2025 |
