| Zeebrugge 20 November 2010 |
 |
 |
 |
 |
 |
||||
| Zeebrugge 20/11/10 | Zeebrugge 20/11/10 | Zeebrugge 20/11/10 | Zeebrugge 10/03/15 | Zeebrugge | ||||
|
Name |
CYGNUS LEADER |
|
Type |
Roll-On/Roll-Off carrier - Vehicles carrier |
|
IMO-number |
9381249 |
|
Call sign |
3EKK5 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
61.775 |
|
DWT |
20.180 t |
|
NT |
18.533 |
|
Length |
199,94 m over all |
|
Breadth |
32,26 m |
|
Draught |
Summer: 10,016 m |
|
Moulded L x B x D |
190,00 x 32,26 x 15,00 m |
|
Registered L x B x D |
194,11 x 32,26 x 24,32 m |
|
Freeboard |
Summer: 5.025 mm |
|
Depth |
15,00 m moulded |
|
Built |
2007 |
|
Keel laid |
08/11/2006 |
|
Launch date |
21/03/2007 |
|
Date of completion |
30/05/2007 |
|
Builder |
Imabari Shipbuilding Co., Ltd. Marugame Headquarters Marugame Japan |
|
Yard number |
1489 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Main engine |
1x Mitsubishi 8UEC60LSII - 2 stroke single acting 8 cylinder 600 x 2.300 mm combustion engine 15.540 kW / 20.823 hp at 104,0 rpm Manufacturer: Kobe Diesel Co., Ltd. |
|
Propeller shaft |
1x Oil lubrication shaft with monitoring device Diameter: 650 mm |
|
Number of screws |
1x Fixed keyless propeller |
|
Boiler |
1x Auxiliary vertical boiler - 7,8 bar Evaporation: 4,60 t/h Manufacturer: Osaka Boiler Mfg., Co., Ltd. |
|
Generators |
4x Generatorsets total 4.245 kVA |
|
Number of car decks |
12 |
|
Ramps |
1x Quarter ramp 1x Side ramp |
|
Cargo capacity |
Cars: 5.415 Trucks: 162 |
|
Tank capacities |
Fuel oil: 3.637 m³ Fresh water: 369 m³ Water ballast: 9.450 m³ |
|
Lifting equipment |
2x Cranes - SWL 0,9 t 3x Cranes - SWL 4,0 t |
|
Crew |
20 |
|
ISM & commercial manager |
Wilhelmsen Ship Management SND BHD Kuala Lumpur Malaysia |
|
Previous managers |
Shoei Kisen Kaisha, Ltd., Imabari - Japan |
|
Registered owner |
Kiyomi Maritima SA, c/o Wilhelmsen Ship Management, Kuala Lumpur Malaysia |
|
Previous owner |
Pedregal Maritime S.A. |
|
Latest data adjustment |
25 March 2025 |
