Diagoras - IMO 8916126

Name

DIAGORAS

Previous names

1990 - 04.2000 New Tosa - Osaka Kochi Tokkyu Ferry

04.2000 - 10.2000 Panagia Skiadeni

10.2000 - 09.2001 Lindos - D.A.N.E. Sea Line

2001 - 2004 Diagoras - D.A.N.E. Sea Line

2004 - 2006 Diagoras

Type

Roll-On/Roll-Off passengers vessel - Ferry (closed)

IMO-number

8916126

Call sign

SXAM

Flag

Greece

Port of registry

Piraeus

Previous flags

1990 - 04.2000 Japan, Kochi

04.200 - 07.2006 Greece, Rhodos

GT

12.499 t

DWT

3.348 t

NT

6.506 t

Length

141,54 m overall

130,00 m between perpendiculars

Breadth

23,00 m

Draught

5,71 m

Lanemetres

900 m

Freeboard

1.814 mm

Depth

12,70 m

Speed

Service: 21,0 knots

Max.: 22,0 knots

Line

Blue star Ferries Line

Route

1990 - 2000 Kochi - Osaka
09.2001 - 06.2004 Piraeus - Rhodes
06.2004 Piraeus - Kalymnos - Kos - Rhodes / Astypalaia - Patmos - Lipsi - Leros - Nisyros - Tilos - Symi - Kastelorizo

Pireus - Astypalea - Kalymnos - Kos - Rhodos

Built

1990

Launch date

25.12.1989

Date of completion

01.01.1991

Builder

Naikai Shipbuilding & engineering Co. Ltd.
Setoda
Hiroshima
Japan

Rebuild

10.2000 - 09.2001 Perema, Piraeus - Greece

Yard number

548

Hull material

Steel

Hull type

Single hull

Main engine

2x Nigata-Pielstick 12PC2-6V-400 - 4 stroke 12 cylinder 400 x 460 mm diesel engines - each 5.759 kW total 11.518 kW / 15.650 hp at 520 rpm

Builder: Pielstick Nigata Engineering Co.

Propellers

2x Screw propeller solid - aft at 180 rpm

Boilers

1x CHM 22,40 m² - 8,0 bar
2x CHR 59,04 m² - 11,5 bar

Diesel generators

1x Main diesel generatorset 1.475 kVA - 1.180 kW - 1.750 hp 450 VAC 60 Hz
2x Main diesel generatorsets each 1.525 kVA - 1.220 kW - 1.780 hp 450 VAC 60 Hz

Emergency generators

1x Diesel generatorsets 315 kVA - 252 kW - 380 hp

Number of decks

2

Number of Passengers

1.462

Number of berths

400

Car capacity

274

Cabins

141

Tank capacities

Fuel oil: 630,3 m³

Manager

Blue Star Ferries Maritime
Athens
Greece

Operator

Blue Star Ferries

Owner

07.2006 Blue Star Ferries Maritime SA.
Piraeus

Greece

Previous owners

1990 - 04.2000Osaka Kochi Tukkyu Ferry, Kochi - Japan
09.2000 - 07.2006 DANE Sea Line (Dodekanissiaki Anonimos Etairia Naftialiaki),Rhodes - Greece

Latest data adjustment

24 October 2015
