Westerschelde 07 July 2017 |
 |
 |
 |
 |
|||
| Zeebrugge 29/10/16 | Zeebrugge 24/03/19 | Zeebrugge 24/03/19 | Zeebrugge 24/03/19 | |||
|
Name |
DIGNITY ACE |
|
Type |
Roll-On/Roll-Off vehicles carrier |
|
IMO-number |
9441506 |
|
Call sign |
C6WY6 |
|
Flag |
Bahamas |
|
Port of registry |
Nassau |
|
GT |
58.767 |
|
DWT |
Summer: 20.589 t |
|
NT |
19.972 |
|
Length |
199,95 m overall 191,00 m between perpendiculars |
|
Breadth |
32,29 m extreme |
|
Draught |
Summer: 10,02 m |
|
Depth |
14,40 m |
|
Speed |
Service: 20,5 knots Max: 21,5 knots |
|
Built |
2010 |
|
Keel laid |
14/01/2010 |
|
Launch date |
20/04/2010 |
|
Date of completion |
01/19/2010 |
|
Builder |
Hyundai Mipo Dockyard Co., Ltd. |
|
Yard number |
8036 |
|
Hull material |
Steel |
|
Main engine |
1x HHI/MAN B&W 7S60MC-C - 2 stroke single acting 7 cylinder 600 x 2?400 mm combustion engine 14.280 kW / 19.415 hp at 105,0 rpm Builder: Hyundai Heavy Industries Co Ltd - South Korea |
|
Propellers |
1x Fixed pitch propeller - aft at 105,0 rpm |
|
Boilers |
1x Auxiliary boiler, exhaust gas heated (Economizer) 1x Auxiliary boiler, oil/gas fired |
|
Generators |
3x Hyundai/Himsen 6H25/33 - 4 stroke 6 cylinder 250 x 330 mm diesel engines each 1.740 kW connected with 3 generators each 1.740 kW Builder: Hyundai Engine & Machinery Co. Ltd. |
|
Emergency generator |
1x Doosan AD126TIS generatorset Builder: Doosan Infracore Co., Ltd. |
|
Bow thruster |
1x Tunnel thruster 1.400 kW / 1.903 bhp, forward |
|
Number of decks |
12 Incl. 4 hoistable decks |
|
Number of cars |
6.500 |
|
Tank capacities |
Ballast: 8.906,1 m³ |
|
Anchor equipment |
Length: 687,50 m Diameter: 81 mm |
|
Crew |
25 |
|
Commercial manager |
Ray Car Carriers Ltd. 33-37, Athol Street Douglas Isle of Man - United Kingdom |
|
Manager |
Stamco Ship Management Co. Ltd. 21, Akti Miaouli 185 35, Piraeus Greece |
|
Registered owner |
Dignity Maritime Limited c/o Ray Car Carriers Ltd. 33-37, Athol Street Douglas Isle of Man - United Kingdom |
|
Latest data adjustment |
28 March 2025 |
