| Zeebrugge 09 October 2005 |
|
Name |
DON QUIJOTE |
|
Type |
Roll-On/Roll-Off vehicles Carrier PCTC - Pure Car and truck Carrier |
|
IMO-number |
9138525 |
|
Call sign |
SFQP |
|
Flag |
Sweden |
|
GT |
56.893 |
|
DWT |
14.927 t |
|
DWT at max. draft |
22.693 t |
|
NT |
23.693 |
|
Length |
199,10 m overall 190,50 m between perpendiculars |
|
Breadth |
32,26 m moulded |
|
Draught |
Summer: 9,50 m |
|
Air Draft |
47,92 m |
|
Height to upperdeck |
33,48 m |
|
Freeboard |
4.550 mm |
|
Depth |
14,05 m |
|
Speed |
20,5 knots |
|
Built |
1998 |
|
Date of order |
01/07/1996 |
|
Date of completion |
02/1998 |
|
Builder |
Daewoo Heavy Industry Ltd Okpo South-Korea |
|
Yard number |
4417 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Main engine |
1x MAN-B&W 8S60MC - 8 cylinder combustion engine 14.700 kW / 20.000 bhp at 101,3 rpm |
|
Number of screws |
1 |
|
Shaft generator |
1x 950 kW |
|
Electrical power |
2x Wärtsilä 4R32 diesel engines each connected with generators each 1.400 kW / 440 Volt 60 Hz |
|
Emergency power |
1x Diesel generatorset 165 kW |
|
Bow thruster |
1.500 kW by 23,5 t thrust |
|
Stern ramp |
Width:7,00 m Height:5,00 m Capacity:125 t |
|
Number of car decks |
13 (of which 3 are hoist able) |
|
Capacity deck area |
52.357 m² |
|
Capacity of car units (RT 43) |
5.873 units One RT43 unit = 7,38975 m² |
|
Capacity of cars / trucks |
2.949 / 488 |
|
Basic complement |
15 |
|
Manager |
Wallenius Lines AB Stockholm Sweden |
|
Operator |
Wallenius Wilhelmsen |
|
Owner |
Wallenius Lines AB Stockholm Sweden |
|
Latest data adjustment |
01 April 2025 |
