| Westerschelde 30 July 2014 |
 |
 |
 |
 |
|||
| Antwerpen 27/04/14 | Antwerpen 27/04/14 | Antwerpen 30/07/14 | Antwerpen 30/07/14 | |||
|
Name |
DRESDEN |
|
Type |
Roll-On/Roll-Off cargo ship - Vehicles Carrier PCTC - Pure Car and Truck Carrier |
|
IMO-number |
9177040 |
|
Call sign |
5BTV3 |
|
Flag |
Cyprus |
|
Port of registry |
Limassol |
|
Previous flags |
2000 - 2000 Norway 2000 - 2002 Liberia 2002 - 2012 Republic of Panama - Call sing: HOLO |
|
GT |
37.237 |
|
DWT |
12.743 t |
|
NT |
11.172 |
|
Length |
176,50 m overall 165,00 m between perpendiculars |
|
Breadth |
31,10 m overall |
|
Draught |
Summer: 8,75 m |
|
Air draft |
45,20 m |
|
Freeboard |
Summer: 5.726 mm |
|
Depth |
28,00 m moulded |
|
Speed |
19,5 knots |
|
Built |
2000 |
|
Keel Laid |
16/07/1999 |
|
Launch date |
29/01/2000 |
|
Date of completion |
31/05/2000 |
|
Builder |
Brodogradiliste Uljanik Shipyard Flaciusova 1 HR-52100 Pula Croatia |
|
Yard number |
421 |
|
Hull material |
Mild steel |
|
Hull type |
Single hull |
|
Bulkheads |
5 |
|
Main engine |
1x MAN-B&W 7S50MC-C - 7 cylinder combustion engine 15.027 hp / 11.060 kW at 127,0 rpm Builder: Uljanik, Croatia |
|
Number of screws |
1x Screw propeller solid |
|
Boilers |
1x CHM TPK Kotlogradnja Zag - 7,0 bar Heating surface: 165,00 m² Composite K/KD - TPK NOVA Ltd. |
|
Generator |
3x MAN-B&W 6L23/30 generatorsets each 1.140 kVA - 912 kW - 1.304 hp |
|
Emergency generator |
1x Man D2866TE diesel generatorset 206 kVA - 165 kW - 272 hp |
|
Bow thrusters |
1x 800 kW, stern 1x 1.000 kW, forward |
|
Car capacity |
4.310 |
|
Number of car decks |
10 |
|
Ramp capacity |
Stern ramp - SWL: 100 t Midship ramp - SWL: 20 t |
|
Tank capacities |
Ballast: 4.361,58 m³ Fresh water: 167,55 m³ HFO: 2.409,90 m³ MDO: 208,00 m³ |
|
Lifting equipment |
1x Engine room overhead crane - SWL 2,0 t 1x Crane - SWL 5,2 t |
|
Manager |
Star Reefers Poland Sp. z o.o. |
|
Previous manager |
2002 - 2013 Wilhelmsen Ship Management Sdn Bhd, Kuala Lumpur Centra - Malaysia |
|
Operator |
RMR Hazeldonk 6262 4836 LG Breda The Netherlands |
|
Owner |
SCC Ship owning II DA Jerpefaret 12 0788 Oslo Norway |
|
Previous owners |
2000 - 2002 Providence Shipping Inc., Hamburg - Germany |
|
Renamed |
07/2017 Chang Sheng Hong China, Shenzhen - Call sign: BRTQ
|
|
Latest data adjustment |
03 April 2025 |
