Name
|
ELBE HIGHWAY
|
|
Type
|
Vehicle Carrier
|
|
IMO-number
|
9316282
|
|
Call sign
|
C6UR3
|
|
Flag
|
Bahamas
|
|
Port of registry
|
Nassau
|
|
GT
|
23.498 t
|
|
DWT
|
7.750 t
|
|
NT
|
7.243 t
|
|
Length
|
147,93 m overall
134,00 between perpendiculars
|
|
Breadth
|
26,40 m extreme
25,00 m moulded
|
|
Draught
|
Summer: 7,90 m
|
|
Freeboard
|
3.914 mm
|
|
Depth
|
25,20 m
|
|
Speed
|
Service: 18,9 knots
|
|
Built
|
2005
|
|
Keel laid
|
19/04/2005
|
|
Launch date
|
16/07/2005
|
|
Date of completion
|
19/09/2005
|
|
Builder
|
Stocznia Gdynia S.A.
ul. Czechoslowacka 3
81-963 Gdynia
Poland
|
|
Yard number
|
8245/1
|
|
Hull material
|
Steel
|
|
Hull type
|
Single hull
|
|
Main engine
|
1x MAN-B&W-Cegielski 7S46MC-C engine - 2 stroke 7 cylinder combustion engine 9.170 kW / 12.467 bhp
|
|
Number of screws
|
1x Fixed propeller
|
|
Auxiliary boiler
|
1x Exhaust gas smoke tube - KangRim Ind.
1X Horizontal shell type - KangRim Ind.
|
|
Generators
|
3x MAN B&W 7L23/30H main diesel generatorsets each 1.130 kW
|
|
Emergency generator
|
1x D9-95M Scania diesel generatorset
Builder: Scania AB Industrial & Marine Engines
|
|
Thrusters
|
1x 1.200 kW, forward
1x 600 kW; aft
|
|
Number of decks
|
8
|
|
Car capacity
|
2.132
|
|
Anchor chain
|
Length: 577,50 m
Diameter: 60 mm
|
|
Tank capacities
|
Ballast: 3.803,6 m³
|
|
Crew
|
17
|
|
Manager
|
Stargate Shipmanagement GmbH
Otto-Lilienthal-Straße 15
28199 Bremen
Germany
|
|
Previous manager
|
2005 – 2006 Jahre-Wallem AS
Strandpromenaden 9
3201 Sandefjord
Norway
2006 Stamco Ship Management Company Ltd
21, Akti Miaouli Street
185 35 Piraeus
Greece
|
|
Operator
|
Kess
K' Line European Sea Highway Service
Bremen
Federal Republic of Germany
|
|
Registered owner
|
Elbe Maritime Limited
Nassau
Bahamas
|
|
Latest data adjustment
|
25 June 2018
|
