Zeebrugge 28 May 2021 |
 |
 |
 |
 |
 |
 |
|||||
| Zeebrugge 28/05/21 | Zeebrugge 28/05/21 | Zeebrugge 20/06/21 | Westerschelde 09/08/16 | Zeebrugge 26/09/09 | Zeebrugge 31/08/09 | |||||
 |
||||||||||
| Westerschelde 27/06/17 | ||||||||||
|
Name |
ELEKTRA |
|
Type |
Vehicles Carrier - Handysize PCTC - Pure Car and Truck Carrier |
|
IMO-number |
9176577 |
|
Call sign |
9V8798 |
|
Flag |
Republic of Singapore |
|
Port of registry |
Singapore City |
|
Previous flags |
1999 - 2011 Sweden, Stockholm - Call sign: SIWB |
|
GT |
67.264 t |
|
DWT |
28.636 t |
|
NT |
28.473 t |
|
Length |
227,95 m overall |
|
Breadth |
32,26 m moulded |
|
Draught |
Summer: 11,02 m |
|
Air Draft |
47,92 m |
|
Freeboard |
21.270 mm |
|
Height to upperdeck |
33,48 m |
|
Depth |
14,05 m |
|
Speed |
20,5 knots |
|
Built |
1999 |
|
Date of completion |
05/1999 |
|
Builder |
Daewoo Shipbuilding & Marine Engineering Goeje South Korea |
|
Yard number |
4420 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Main engine |
1x KHIC/MAN-B&W 8S60MC - 2 stroke 8 cylinder combustion engine 14.700 kW at 101,3 rpm |
|
Number of screws |
1x Fixed propeller |
|
Shaft generator |
1x 950 kW |
|
Generators |
2x Wärtsilä type 4R32 diesel engines each connected with generators each 1.400 kW / 3x 440 Volt, 60 Hz |
|
Emergency generator |
1x Diesel generatorset 165 kW |
|
Bow thruster |
1.500 kW, forward 750 kW, aft |
|
Stern ramp |
Width: 7,00 m Height: 5,00 m Capacity: 125 t |
|
Number of car decks |
13 (of which 3 are hoistable) |
|
Capacity deck area |
63,124 m² |
|
Capacity of car units (RT 43) |
7.194 one RT43 unit = 7,38975 m² |
|
Capacity of cars / trucks |
3.700 / 600 |
|
Basic complement |
15 |
|
Crew |
20 |
|
Manager |
Wallenius Marine Singapore Pte Ltd. |
|
ISM manager |
Wallenius Marine AB Stockholm Sweden |
|
Operator |
Wallenius Wilhelmsen |
|
Owner |
WWL Shipowning Singapore Pte. |
|
Previous owners |
Wallenius Lines AB, Stockholm - Sweden |
|
Remarks |
Elektra was elongated in 2005 by 28 metres Wallenius Lines reveals that the lengthening of five Boheme-class ships the MIGNON, ELEKTRA, BOHEME, MANON & UNDINE will be handled by Hyundai Mipo Dockyards’ Vinashin facility in Vietnam. Capacity will be raised from 5.900 to 7.100 cars. |
|
Latest data adjustment |
04 March 2023 |
