| Westerschelde 17/10/15 |
 |
 |
 |
 |
 |
||||
| Zeebrugge 12/05/08 | Zeebrugge 12/05/08 | Zeebrugge 12/05/08 | Zeebrugge 10/08/09 | Westerschelde 22/08/18 |
|
Name |
FEDORA |
|
Type |
Roll-On/Roll-off carrier - Vehicles Carrier PCTC - Pure Car and Truck Carrier |
|
IMO-number |
9332949 |
|
Call sign |
SLKU |
|
Flag |
Sweden |
|
Port of registry |
Stockholm |
|
GT |
71.583 t |
|
DWT |
30.386 t at maximum draft |
|
NT |
33.546 t |
|
Length |
227,80 m overall |
|
Breadth |
32,26 m moulded |
|
Draught |
Summer: 11,30 m |
|
Height to upperdeck |
34,70 m |
|
Air draft |
51,98 m |
|
Speed |
20,0 knots |
|
Built |
2008 |
|
Date of completed |
02/2008 |
|
Builder |
Daewoo Shipbuilding & Heavy Engineering Co. Okpo South Korea |
|
Yard number |
4446 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Main engine |
1x MAN-B&W 7S60MC-C - 7 cylinder combustion engine 15.816 kW / 21.490 hp at 105,0 rpm |
|
Propeller |
1x Fixed propeller |
|
Shaft generator |
1.000 kW |
|
Generators |
2x MAN-B&W SL21/31H diesel generatorsets each 1.700 kW 450 Volt, 60 Hz |
|
Emergency generator |
1x Diesel generatorset 215 kW |
|
Bow thruster |
1x Kamewa Ulstein 2.000 kW thrust force 30,0 t |
|
Number of decks |
13 (of which 5 are movable) |
|
Capacity deck area |
67.300 m² |
|
Car capacity RT43 |
7.500 1 RT43 gross unit abt. 8,4 m² |
|
Capacity cars / truck |
3.484 / 468 |
|
Stern ramp capacity |
Width: 9,50 m Height: 6,50 m Ramp weight capacity: 240 t |
|
Complement |
33 |
|
Crew |
21 |
|
Manager |
Wallenius Lines AB Stockholm Sweden |
|
Operator |
Wallenius Wilhelmsen Logistics |
|
Owner |
Wallenius Lines AB Stockholm Sweden |
|
Renamed |
2019 ARC Integrity United States of America, Wilmington, DE - Call sign: KINQ Reg. owner: ARC Integrity Trust |
|
Latest data adjustment |
10 November 2021 |
