| Zeebrugge 07 June 2004 |
 |
 |
|
| Zeebrugge 26/03/04 | Zee 07/06/04 | |
|
Name |
FEEDERMATE |
|
Type |
Roll-On/Roll-Off vehicles carrier PCC - Pure Car Carrier |
|
IMO-number |
9179983 |
|
Call sign |
CQXS |
|
Flag |
Portugal |
|
Port of registry |
Madeira |
|
Previous flag |
1198 - 2004 Norway - Call sign: LACR6 |
|
GT |
9.233 |
|
DWT |
3.347 t |
|
NT |
2.940 |
|
Length |
99,99 m overall 94,65 m between perpendiculars |
|
Breadth |
19,83 m extreme 19,50 m moulded |
|
Draught |
Summer: 5,50 m |
|
Depth |
18,50 m |
|
Speed |
Max: 18,0 knots Service: 15,5 knots |
|
Build |
1998 |
|
Keel laid |
30/01/1998 |
|
Launch date |
21/08/1998 |
|
Date of completion |
04/11/1998 |
|
Builder |
Hegemann Rolandwerft G.m.b.H Bremen Germany |
|
Yard number |
184 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Main engine |
2x MaK 8M25- 8 cylinder combustion engine total 4.800 kW / 6.526 bhp at 720 rpm Builder: Mak Maschinenbau GmbH, Kiel - Germany |
|
Number of screws |
2x KaMeWa controllable pitch propellers Diameter: 3.400 mm |
|
Generators |
1x Caterpillar 3304B - 4 stroke 4 cylinder 121 x 152 mm diesel generatorset Mcr 120 kW 2x Yanmar 6N16SL-EN- 4 stroke 6 cylinder 165 x 232 mm diesel generatorsets each Mcr 441 kW |
|
Bow thruster |
1x Ulstein 700 kW |
|
Car capacity |
875 |
|
Ramp capacity |
Stern ramp: 14,00 x 5,00 m Center ramp: 14,00 x 4,00 m Capacity: 5,0 t Max. height: 3,80 m |
|
Tank capacities |
Ballast: 125 m³ Diesel oil: 500 m³ Lub oil: 30 m³ Fresh water: 100 m³ |
|
Operator |
K-Line / Kawasaki Kisen Kaisha Line |
|
Owner |
Feedermate Transportes Maritimos Ltda. Portugal |
|
Renamed |
05/2001 Main Highway Cyprus, Limassol - Call sign: P3ZV9
12/2022 Won Shin Republic of Panama, Panama City - Call sign: 3E3517
04/2024 Erk Izmir Republic of Panama, Panama City - Call sign: 3E3517
|
|
Latest data adjustment |
14 April 2025 |
