Florida Highway 18

Zeebrugge 26 June 2018



Florida Highway 19   Florida Highway 01   Florida Highway 16   Florida Highway 17
Zeebrugge 26/06/18 Zeebrugge 02/07/09 Zeebrugge 09/08/09 Zeebrugge 09/08/09



Name

FLORIDA HIGHWAY

Type

Vehicles carrier

IMO-number

9442861

Call sign

3EPT6

Flag

Republic of Panama

Port of registry

Panama City

GT

59.493 t registered

DWT

Summer: 18.930 t

NT

19.244 t registered

Length

199,97 m overall

190,00 m between perpendiculars

Breadth

32,26 m

Moulded LxBxD

192,00 x 32,26 x 14,70 m

Registered LxBxD

194,14 x 32,26 x 21,31 m

Draught

Summer: 10,017 m

Freeboard

Summer: 4.715 mm

Built

2008

Keel laid

04.10.2007

Launch date

26.01.2008

Date of completion

26.03.2008

Builder

Imabari Shipbuilding Co., Ltd.
Marugame Headquarters
Marugame
Japan

Yard number

1471

Hull type

Single hull

Main engine

1x 2 Stroke single acting 8 cylinder 600 x 2.300 mm engine – 13.260 kW at 100,00 rpm

Manufacturer: Kobe Diesel Co., Ltd.

Propeller shaft

1x Oil lubrication shaft with monitoring device

Diameter: 630 mm

Propellers

1

Boiler

1x Auxiliary vertical boiler – 7,8 bar
Evaporation: 4,04 t/h
Manufacturer: Miura Protec Co., Ltd.

Generators

4x Main diesel generatorsets 4.700 kVA

Cargo capacity

Cars: 6.237

Trucks: 109

Tank capacity

Fuel oil: 3.010 m³

Fresh water: 659 m³

Water ballast: 8.449 m³

Lift equipment

2x Cranes - SWL 0,5 t each

3x Cranes - SWL 4,0 t each

Crew

21

Manager

Shoei Kisen Kaisha S.A.
Imabari
Japan

Operator

K-Line / Kawasaki Kisen Kaisha Line

Registered owner

Pedregal Maritime
Liberia

Owner as completed

Pedregal Maritime S.A.
Panama City
Republic of Panama

Latest data adjustment

04 July 2018
