Heroic Ace 07
Zeebrugge 26 August 2009

Heroic Ace IMO 9252216 11
Westerschelde 27/09/15


Name

HEROIC ACE

Type

Roll-On/Roll-Off carrier - Vehicles carrier

PCTC - Pure Car and Truck Carrier

IMO-number

9252216

Call sign

HPFM

Flag

Republic of Panama

Port of registry

Panama City

GT

56.439 t registered

DWT

19.879 t

NT

17.959 t registered

Length

198,00 m overall

188,00 m between perpendiculars

Breadth

32,20 m moulded

Moulded L x B x D

188,00 x 32,20 x 14,60 m

Registered L x B x D

190,90 x 32,20 x 21,09 m

Draught

Summer: 9,92 m

Freeboard

Summer: 4.714 mm

Speed

20,0 knots

Trial: 21,8 knots

Built

2003

Keel laid

14/06/2002

Launch date

18/03/2003

Date of completion

20/06/2003

Builder

Minaminippon Shipbuilding Co., Ltd.

Usuki

Japan

Yard number

675

Main engine

1x Mitsubishi/Kobe Diesel 8UEC60LS - 2 stroke single acting 8 cylinder 600 x 2.200 mm combustion 14.160 kW / 19.252 hp at 100,0 rpm

Manufacturer: Kobe Diesel Co., Ltd. Nagasaki Works - Japan

Propellers

1

Boilers

1x Auxiliary vertical boiler - 7,8 bar

Evaporation: 2,91 t/h

Manufacturer: Miura Co., Ltd.

Generators

4x Main diesel generatorsets each 3.870 kVA

Thruster

1x 1.250 kW, forward

1x 800 kW, stern

Car decks

13

Car capacity

5.281

Number of ramps

2

Tank capacities

Fuel oil: 3.192 m³

Fresh water: 331 m³

Water ballast: 7.340 m³

Crew

24

Commercial manager

Mitsui O. S. K. Line (MOL)

1-1, Toranomon 2-chome, Minato-ku

Tokyo, 105-8688

Japan

ISM manager

MOL Ship Management (Singapore) Pte. Ltd.

17-04, UIC Building, 5, Shenton Way

Singapore 068808

Republic of Singapore

Registered owner

Aurora Car Maritime Transport S.A. - Republic of Panama

Care of Mitsui OSK Lines Ltd (MOL)

1-1, Toranomon 2-chome, Minato-ku

Tokyo, 105-8688

Japan

Latest data adjustment

24 January 2024
