| Piraeus, Greece 11 June 2014 |
 |
 |
|
| Piraeus, Greece 27/08/12 | Piraeus, Greece 25/08/12 | |
|
Name |
HIGHSPEED 4 |
|
Hellenic name |
ΧΑΪΣΜΙΝΤ 4 |
|
Type |
High speed craft - Catamaran Roll-On/Roll-Off Passengers vessel / Car ferry |
|
IMO-number |
9216183 |
|
Call sign |
SWJD |
|
Flag |
Greece |
|
Port of registry |
Piraeus |
|
GT |
6.274 |
|
DWT |
Summer: 470 t |
|
NT |
1.882 |
|
Length |
92,60 m overall 77,73 m between perpendiculars 80,80 m registered |
|
Breadth |
24,01 m moulded |
|
Draught |
3,86 m |
|
Freeboard |
3.936 mm |
|
Depth |
7,80 m moulded |
|
Speed |
Max: 38,0 knots |
|
Built |
2000 |
|
Keel laid |
01/07/1999 |
|
Launch date |
30/04/2000 |
|
Date of completion |
01/07/2000 |
|
Builder |
Austal Ships Pty. Ltd. 100, Clarence Beach Road Henderson ,6166 Western Australia Australia |
|
Yard number |
97 |
|
Hull material |
Aluminium alloy High resistance and ordinary |
|
Watertight bulkheads |
7 |
|
Number of complete decks |
5 |
|
Main engine |
4x Caterpillar 3618 - 4 stroke 18 cylinder 137 x 152 mm combustion engines each 7.200 kW at 1.050 rpm Total 28.800 kW Year of manufacture: 1999 Manufacturer: Caterpillar Tractor Co. Peoria, Illinois 61629 United States of America |
|
Propulsion |
4x KaMeWa112 sII waterjest - aft at 500 rpm |
|
Electric installation |
4x Plants each 380/220 V - 350 kVA |
|
Generators |
4x Main generatorsets each 350 kVA |
|
Compressed air receivers |
2x Receivers each 660 litres - 30,0 bar 1x Receiver 150 litres - 30,0 bar |
|
Number of passengers |
1.010 |
|
Number of cars |
188 |
|
Tank capacities |
Fuel: 332 m³ |
|
Crew |
36 |
|
ISM & commercial manager |
Hellenic Seaways Maritime S.A. 1-7, Lysikratous & Evripidou Streets Kallithea, 176 74, Athens Greece |
|
Operator |
Hellenic Seaways |
|
Registered owner |
Hellenic Seaways Maritime S.A. 1-7, Lysikratous & Evripidou Streets Kallithea, 176 74, Athens Greece |
|
Previous owners |
2000 - 2001 Minoan Flying Dolphins 2001 - 2005 Hellas Flying Dolphins |
|
Latest data adjustment |
14 May 2025 |
