Westerschelde 28 June 2018 |
 |
 |
|
| Zeebrugge 03/03/10 | Zeebrugge 03/03/10 |
|
Name |
MORNING CONDUCTOR |
|
Type |
Vehicles Carrier |
|
IMO-number |
9336050 |
|
Call sign |
3EOF5 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
57.542 t |
|
DWT |
21.091 t |
|
NT |
20.901 t |
|
Length |
199,97 m overall |
|
Breadth |
32,26 m |
|
Reg. Dimensions L x B x D |
193,13 x 32,26 x 20,11 m |
|
Rule Dimensions L x B x D |
189,20 x 32,26 x 14,30 m |
|
Draught |
Summer: 10,017 m |
|
Freeboard |
Summer: 3.534 mm |
|
Depth |
19,93 m |
|
Speed |
20,5 knots |
|
Built |
2008 |
|
Keel laid |
18.06.2007 |
|
Launch date |
22.09.2007 |
|
Date of completion |
02.01.2008 |
|
Builder |
Hyundai Samho Heavy Industries Co., Ltd. 1700, Yongdang-Ri, Samho-Eup 526-701 Youngam-Gun Republic of Korea |
|
Yard number |
S-0290 |
|
Hull type |
Single hull |
|
Transportable bulkheads |
4x Watertight |
|
Main engine |
1x 2 stroke single acting 7 cylinder 600 x 2.292 mm diesel engine output 14.280 kW at 105,0 rpm Built: 2007 Builder: Hyundai Heavy Ind. Engine & Machinery Ulsan South Korea |
|
Number of screws |
1 |
|
Boilers |
1x Auxiliary water tube boiler - 8,8 kg/m² Heating surface: 24,0 m² 1x Auxiliary water tube boiler - 12,0 kg/m² Heating surface: 226,5 m² Built:2007 Builder:Kang Rim ind. Co., Ltd. Shang Hai People's Republic of China |
|
Generators |
4x Main diesel generatorsets each 1.475 kVA - 450 Volt |
|
Car capacity |
6.500 |
|
Number of decks |
7 |
|
Tank capacities |
Fuel oil: 4.130 m³ Fresh water: 323 m³ Water ballast: 5.877,10 m³ |
|
Crew |
21 |
|
Manager |
EUKOR Car Carriers Inc. |
|
Previous manager |
2008 - 2008 Wilhelmsen Ship Management (Korea) Ltd. 10th Floor Marine Center Bldg. 79-1, 4-ga Jungang- Dong, Jung-Gu 600-715 Pusan Republic of Korea |
|
Technical Manager |
Haeyoung Maritime Services Co., Ltd. 7th Fl., Busan Postoffice Building Jungang-Dong, 3- Ga, Jung-Gu 600-711 Busan Republic of Korea |
|
Operator |
EUKOR |
|
Owner |
EUKOR Car Carriers International S.A 13th Floor Hansol B/D, 736-1 Yeoksam-Dong Kangnam-Gu 135-983 Seoul Republic of Korea |
