Walsoorden, The Netherlands 01 May 2022 |
 |
 |
 |
 |
|||
| Westerschelde 09/10/14 | Westerschelde 29/07/15 | Westerschelde 12/12/18 | Westerschelde 22/02/18 | |||
|
Name |
GRANDE GHANA |
|
Type |
RoCon - Roll-On/Roll-Off cargo vessel - Equipped for carriage of containers |
|
IMO-number |
9343168 |
|
Call sign |
ICEZ |
|
Flag |
Italy |
|
Port of registry |
Palermo |
|
GT |
47.128 t |
|
DWT |
36.855 t |
|
NT |
14.134 t |
|
Number of 20ft containers |
1.360 |
|
Reefer containers |
25 |
|
Length |
210,92 m overall 196,80 m between perpendiculars |
|
Breadth |
32,26 m moulded |
|
Draught |
9,75 m |
|
Lanemetres |
2.500 m |
|
Depth |
13,34 m |
|
Speed |
Max: 21,9 knots |
|
Built |
2009 |
|
Keel laid |
11/04/08 |
|
Date of completion |
11/02/2009 |
|
Builder |
Uljanik Shipyard (Brodogradiliste uljanik) Pula Croatia |
|
Yard number |
473 |
|
Hull material |
Steel - High resistance and ordinary |
|
Hull type |
Single hull, double bottom |
|
Main engine |
1x MAN-B&W/Uljanik 8S60MC-C - 2 stroke 8 cylinder 200 x 2.400 mm combustion engine 19.040 kW Builder: Brodogradiliste 'Uljanik' d.d. (MAN B&W), Pula - Croatia |
|
Propellers |
1x Controllable pitch propeller |
|
Shaft generator |
1x 1.400 kW |
|
Generators |
4x Main diesel generatorsets each 1800 kW |
|
Bow thruster |
2x 1.000 kW, forward 1x 1.000 kW, aft |
|
Car capacity |
3.890 |
|
Truck capacity |
194 |
|
Cargo gear |
2x Cranes - SWL 40,0 t each |
|
Number of decks |
Complete decks: 4 Partial decks: 8 |
|
Number of passengers |
12 |
|
Crew |
30 |
|
Commerical manager |
Grimaldi Group (Grimaldi Compagnia de Navigazione S.p.A) Via Marchese Campodisola 13 80133 Naples NA Italy |
|
ISM Manager |
Grimaldi Deep Sea Spa Via Marchese Campodisola 13 80133 Naples NA Italy |
|
Operator |
Grimaldi Lines |
|
Registered owner |
Grimaldi Deep Sea Spa Via Marchese Campodisola 13 80133 Naples NA Italy |
|
Latest data adjustment |
25 March 2024 |
