| Zeebrugge 05 July 2022 |
 |
 |
 |
 |
 |
||||
| Zeebrugge 11/10/08 | Zeebrugge 11/10/08 | Zeebrugge 11/10/08 | Zeebrugge 11/10/08 | Zeebrugge 13/04/15 |
|
Name |
TALISMAN |
|
Type |
Roll-On/Roll-Off vehicle carrier |
|
IMO-number |
9191319 |
|
Call sign |
LAOW5 |
|
Flag |
Norway |
|
Port of registry |
Tønsberg |
|
GT |
67.140 t |
|
DWT |
38.500 t at maximum draft |
|
NT |
23.674 t |
|
Number of 20ft containers |
1.935 |
|
Length |
240,60 m overall |
|
Breadth |
32,26 m moulded |
|
Draught |
Summer: 11,77 m |
|
Air Draft |
46,00 m |
|
Freeboard |
20.750 mm |
|
Depth |
32,45 m to upper deck |
|
Speed |
20,0 knots |
|
Built |
2000 |
|
31/01/2000 |
|
|
29/04/2000 |
|
|
Date of completion |
30/06/2000 |
|
Builder |
Daewoo Heavy Industries Shipbuilding & Marine Engineering Co., Ltd |
|
Yard number |
4424 |
|
Hull material |
Steel |
|
Bulkheads |
Transverse: 4 |
|
Hull type |
Single hull |
|
Main engine |
1x MAN-B&W 8L70MC (MK5) - 2 stroke 8 cylinder 700 x 2.268 mm combustion engine maximum output of 28.480 bhp / 20.960 kW at 106,0 rpm |
|
Propeller |
1x Fixed pitch propeller |
|
Boilers |
1x Thermal oil heater, exhaust heated |
|
Generators |
2x MAN B&W 6L28/32H diesel generatorsets each 1.710 bhp |
|
Emergency generator |
1x Ssanyong-Cummins diesel generatorset 200 kW at 1.800 rpm |
|
Bow thruster |
1x 1.800 KW, forward |
|
Stern ramp width |
Width: 12,00 m |
|
Number of decks |
8 of which 4 are hoist able |
|
Capacity car units |
5.495 |
|
Capacity deck area |
46.350 m² |
|
Capacity volume |
125.620 m³ |
|
Tank capacities |
Ballast: 15.000 m³ |
|
Ballast capacity |
15.000 m³ |
|
Basic complement |
22 |
|
ISM & commercial manager |
Wilhelmsen Ship Management (Norway) AS |
|
Operator |
WWL - Wilh. Wilhelmsen Lines Group |
|
Owner |
Wilhelmsen Lines Shipowning Malta Ltd. |
|
Latest data adjustment |
18 July 2022 |
