Westerschelde 18 April 2015 |
 |
 |
 |
 |
|||
| Westerschelde 13/11/15 | Westerschelde 19/05/18 | Westerschelde 06/03/18 | Westerschelde 06/03/18 | |||
|
Name |
KRAFTCA |
|
Type |
Roll-On/Roll-Off carrier |
|
IMO-number |
9307360 |
|
Call sign |
PHGY |
|
Flag |
The Netherlands |
|
Port of registry |
Amsterdam |
|
GT |
28.289 t |
|
DWT |
Summer: 17.618 t |
|
NT |
8.486 t |
|
Number of 20ft containers |
643 |
|
Reefer capacity |
20 |
|
Length |
205,00 m overall 190,00 m between perpendiculars |
|
Breadth |
25,50 m moulded |
|
Draught |
8,50 m |
|
Lane metres |
2.800 |
|
Freeboard |
5.609 mm |
|
Depth |
15,65 m |
|
Speed |
Max.: 22,7 knots |
|
Built |
2006 |
|
Launch date |
10/06/2006 |
|
Delivery date |
03/11/2006 |
|
Builder |
Stocznia Szczecinska Nowa Sp. z o.o. Szczecin (Stettin) Poland |
|
Yard number |
B201-II/2 |
|
Hull material |
Steel |
|
Continuous decks |
1 |
|
Main engine |
2x Wärtsilä 12V46C - 4 stroke single acting 12 cylinder 460 x 580 mm diesel engine 25.215 kW / 34.670 hp at 500 rpm Build: 19/10/2005 Manufacturer: Wärtsilä Diesel Oy, Treiste - Italy |
|
Propellers |
2x Controllable pitch propellers - aft at 120,0 rpm |
|
Boilers |
1x CHF Aalborg Industries 65,00 m² - 10,0 bar 1x CHF Aalborg Industries 39,00 m² - 10,0 bar 2x CHR Wiesloch 115,00 m² - 10,0 bar |
|
Generators |
2x Diesel generatorsets each 1.615 kVA - 1.292 kW - 1.848 hp |
|
Emergency generators |
1x Diesel generatorset 625 kVA - 500 kW - 639 hp |
|
Bow thruster |
2x 1.250 kW |
|
Number of holds |
3 |
|
Number of passengers |
12 |
|
Number of beds |
12 |
|
Tank capacities |
Fuel oil: 2.361,2 m³ |
|
Cargo gear |
Gearless |
|
Manager |
Spliethoff´s Bevrachtingskantoor Radarweg 36 1042 AA Amsterdam The Netherlands |
|
Operator |
Transfennica OY Helsinki Finland |
|
Registered owner |
Rederij Kraftca Amsterdam The Netherlands |
|
Previous owners |
11/2006 - 01/2016 C.V. Scheepvaartonderneming Kraftca, Amsterdam - The Netherlands |
|
Group |
Spliethoff |
|
Latest data adjustment |
04 October 2023 |
