Palma De Mallorca 09 June 2016 |
 |
 |
|
| Palma De Mallorca 11/06/16 | Barcelona, Spain 29/08/15 |
|
Name |
SUPER-FAST LEVANTE |
|
Previous names |
2001 - 2005 Superfast Levante |
|
Type |
Roll-On/Roll-Off carrier - Ferry |
|
IMO-number |
9204362 |
|
Call sign |
5BCB4 |
|
Flag |
Cyprus |
|
Port of registry |
Limassol |
|
Previous flags |
03.2001 - 2012 Spain, Santa Cruz de Tenerife - Call sign: EBRF |
|
GT |
17.391 t |
|
DWT |
Summer: 7.200 t |
|
NT |
5.252 t |
|
Length |
157,96 m overall 141,57 m between perpendiculars |
|
Breadth |
25,20 m |
|
Draught |
6,50 m |
|
Lanemetres |
1.905 |
|
Freeboard |
1.212 mm |
|
Depth |
16,60 m |
|
Speed |
Service: 22,0 knots |
|
Route |
2001 - 2012 Cadiz - Canary Islands |
|
Built |
2001 |
|
Launch date |
18.08.2000 |
|
Date of completion |
14.03.2001 |
|
Delivery date |
29.03.2001 |
|
Builder |
UNV - Union Naval Valencia |
|
Yard number |
280 |
|
Hull material |
Steel |
|
Watertight compartments |
12 |
|
Continuous decks |
7 |
|
Main engine |
4x Wärtsilä 6L46C - 4 stroke 6 cylinder 460 x 580 mm diesel engines total 34.268 bhp / 25.204 kW at 500 rpm Built: 2000 Builder: Wärtsilä NSD Iberica, Bermeo - Spain |
|
Propellers |
2x Screw propeller controllable pitch - aft at 180 rpm |
|
Boilers |
1x CHO Aalborg Industries 28,70 m² - 7,0 bar |
|
Electric installations |
Power voltage: 380 V Lighting voltage: 220 V Frequency: 50 Hz |
|
Shaft generator |
2x- 2.000 kVA - 1.600 kW |
|
Generators |
2x Main diesel generatorsets each 1.775 kVA - 1.420 kW - 2.018 hp |
|
Emergency generator |
1x Diesel generatorset 200 kVA - 160 kW - 520 hp |
|
Bow thruster |
2 |
|
Number of passengers |
12 |
|
Number of beds |
12 |
|
Number of cars |
117 |
|
Number of trailers |
102 |
|
Tank capacities |
Fuel oil: 1.369 m³ |
|
Manager |
Acciona Trasmediterranea S.A |
|
Operator |
Trasmediterranea |
|
Owner |
2001 - 2013 Trasmediterranea 2013 - 2014 Maritime Global Operator Ltd. 2014 Schembri Agencia SA |
|
Registered owner |
Maritime Global Operator Ltd. |
|
Latest data adjustment |
04 October 2015 |
