Westerschelde 28 June 2018 |
 |
 |
 |
||
| Westerschelde 11/11/15 | Westerschelde 11/11/15 | Westerschelde 24/07/15 | ||
|
Name |
HÖEGH JACKSONVILLE |
|
Type |
Roll-On/Roll-Off carrier - Vehicles carrier PCTC- Pure Car and Truck Carrier |
|
IMO-number |
9673379 |
|
Call sign |
LATA7 |
|
Flag |
Norway |
|
Port of registry |
Oslo |
|
GT |
58.531 t |
|
DWT |
Summer: 20.578 t |
|
NT |
19.378 t |
|
Length |
199,90 m overall 191,19 m between perpendiculars |
|
Breadth |
32,27 m extreme |
|
Draught |
10,02 m |
|
Depth |
32,59 m |
|
Speed |
Max: 19,9 knots |
|
Built |
2014 |
|
Keel laid |
05/08/2013 |
|
Launch date |
18/01/2014 |
|
Date of completion |
30/04/2014 |
|
Builder |
Daewoo Mangalia Heavy Industries Mangalia Romania |
|
Yard number |
4401 |
|
Hull material |
Steel |
|
Main engine |
1x MAN 5S60ME-C - 2 stroke 5 cylinder 600 x 2.400 mm combustion engine engine 11.328 kW / 15.232 bhp at 105,0 rpm |
|
Propellers |
1x Fixed pitch propeller 4-blades |
|
Boilers |
1x Auxiliary boiler, exhaust gas heated AV-7 1x Auxiliary boiler, oil/gas fired Mission OS Builder: Alfa Laval Aalborg A/S |
|
Generators |
3x MAN B&W 7L28/32H diesel generatorsets each 2.000 kW |
|
Number of cars |
6.500 |
|
Ramp |
Max. deck height: 5,00 m Max. capacity: 150 t Max. width: 15,20 m |
|
Tank capacities |
Ballast: 10.610,2 m³ |
|
Anchor equipment |
Length: 687,50 m |
|
ISM & commercial manager |
Höegh Autoliners Management AS Drammensveien 134 0277 Oslo Norway |
|
Previous managers |
2014 - 2014 Höegh Autoliners 2014 - 2015 Höegh Fleet Services AS |
|
Registered owner |
Höegh Autoliners Shipping AS Drammensveien 134 0277 Oslo Norway |
|
Sister ships |
2010 Höegh Jeddah |
|
Latest data adjustment |
28 September 2024 |
