Name |
CSCC SHANGHAI |
|
Type |
Roll-on/Roll-Off carrier |
|
IMO-number |
9361823 |
|
Call sign |
C6XA5 |
|
Flag |
Bahamas |
|
Port of registry |
Nassau |
|
GT |
41.009 t |
|
DWT |
Summer: 12.300 t |
|
NT |
22.395 t |
|
Length |
176,00 m overall 165,90 m between perpendiculars |
|
Breadth |
31,13 m extreme |
|
Draught |
8,74 m |
|
Air draft |
45,70 m |
|
Freeboard |
5.766 mm |
|
Depth |
30,00 m moulded |
|
Speed |
20,8 knots |
|
Built |
2008 |
|
Keel laid |
15/09/2007 |
|
Launch date |
26/01/2008 |
|
Date of completion |
22/04/2008 |
|
Builder |
Brodogradiliste 'Uljanik' d.d. Flaciusova 1 HR-52100 Pula Croatia |
|
Yard number |
477 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Main engine |
1x MAN-B&W/Uljani 8S50MC-C Mk. VII - 2 stroke 8 combustion diesel engine 12.640 kW / 17.185 hp |
|
Propellers |
1x Wärtsilä fixed pitch propeller |
|
Boilers |
1x Auxiliary boiler, oil/gas fired (Oil fire boiler) KLN/VM-2,5/7 1x Auxiliary boiler, exhaust gas heated (Exhaust boiler) KIP/DV-1/7 Builder: TPK NOVA d.o.o. |
|
Generators |
3x MAN 8L23/30H diesel generatorsets |
|
Emergency generator |
1x Scania D19 diesel generatorset |
|
Bow thruster |
1x 1.000 kW, forward 1x 800 kW, aft Builder: Rolls-Royce Marine AS |
|
Number of cars |
4.900 |
|
Ro-Ro ramps |
1x Starboard dim.: 22,00 x 4,20 x 20,00 m 1x Starboard aft dim.: 32,20 x 7,50 x 12,00 m |
|
Tank capacities |
Ballast: 3.875,4 m³ |
|
Anchor equipment |
Length: 632,50 m Diameter: 70 mm |
|
Crew |
18 |
|
Crew size |
35 |
|
Manager |
Stamco Ship Management Co. Ltd. 21, Akti Miaouli Street 185 35 Piraeus Greece |
|
Operator |
CSCC - China Shipping |
|
Registered owner |
Shanghai Maritime Limited |
|
Renamed |
2018 RCC Shanghai Bahamas, Nassau - Call sign: C6XA5 Owner: Shanghai Maritime Limited Manager: Stamco Ship Management Co. Ltd. |
|
Latest data adjustment |
19 October 2020 |
