Name |
CMA CGM NIAGARA |
|
Type |
Cellular containership |
|
IMO-number |
9722675 |
|
Call sign |
9HA4133 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
GT |
94.440 t |
|
DWT |
110.482 t |
|
NT |
52.015 t |
|
Number of 20ft containers |
10.034 |
|
Reefer capacity |
1.400 |
|
Length |
299,90 m overall 286,00 m between perpendiculars |
|
Breadth |
48,20 m |
|
Draught |
Summer: 14,50 m |
|
Forecastle |
19,05 m |
|
Deckhouse |
5,40 m |
|
Freeboard |
5.836 mm |
|
Depth |
25,00 m |
|
Speed |
Max: 22,0 knots |
|
Built |
2015 |
|
Keel laid |
Steel |
|
Date of completion |
10/11/2015 |
|
Builder |
Samsung Heavy Industries Co., Ltd. Geoje South Korea |
|
Yard number |
2113 |
|
Hull material |
Steel |
|
Bulkheads |
11 |
|
Main engine |
1x MAN-B&W/Doosan 8S90ME-C 9.2 - 2 stroke 8 cylinder 900 x 3.260 mm 46.480 kW / 63.152 hp at 84,0 rpm Build: 27/05/2015 Builder: Doosan Engine Co., Ltd., Gyeongnam - South Korea |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x CHM 1.021,31 m² - 6,0 bar |
|
Generators |
2x Main diesel generatorsets each 4.125 kVA - 3.300 kW - 4.755 hp 2x Main diesel generatorsets each 5.375 kVA - 4.300 kW - 6.114 hp |
|
Emergency generator |
1x Diesel generatorset 375 kVA - 300 kW - 408 hp |
|
Number of cargo holds |
7 |
|
Total capacity of holds |
182.462,9 m³ |
|
Tank capacities |
Fuel: 8.467,1 m³ |
|
Cargo gear |
Gearless |
|
Commercial manager |
CMA CGM SA The French Line 4, quai d'Arenc 13002 Marseille France |
|
ISM manager |
CMA CGM International Shipping 14-01, The Metropolis (Tower 1) 9, North Buona Vista Drive Singapore 138588 Republic of Singapore |
|
Registered owner |
Xintong International Ship Lease Co., Limited Care of CMA CGM SA (The French Line) 4, quai d'Arenc 13002 Marseille France |
|
Latest data adjustment |
30 January 2023 |
