| Westerschelde 16 January 2017 |
 |
 |
 |
||
| Westerschelde 16/01/17 | Zeebrugge 25/02/12 | Zeebrugge 17/02/14 |
|
Name |
CMA CGM NEVADA |
|
Previous name |
CPO Toulon |
|
Type |
Cellular Containership |
|
IMO-number |
9471408 |
|
Call sign |
9HA3474 |
|
Flag |
Liberia |
|
Previous flags |
Liberia - Monrovia - Call sign: A8ZV4 |
|
Port of registry |
Valletta |
|
GT |
140.259 t |
|
DWT |
Summer: 146,182 t |
|
NT |
75.664 t |
|
Number of 20ft containers |
12.562 |
|
Container capacity 14t |
9.080 |
|
Reefer point |
1.000 |
|
Length |
366,14 m overall 350,85 m registered |
|
Breadth |
48,20 m registered |
|
Draught |
Summer: 15,50 m |
|
Depth |
29,80 m to main deck |
|
Speed |
Service: 25,4 knots |
|
Built |
2011 |
|
Builder |
Samsung Heavy Industries Co., Ltd. Geoje Shipyard |
|
Keel laid |
16.05.2011 |
|
Launch date |
29.07.2011 |
|
Date of completion |
04.11.2011 |
|
Yard number |
1818 |
|
Watertight bulkhead |
8 |
|
Continuous decks |
2 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Partly double bottom |
|
Main engine |
1x MAN-B&W 12K98MC-C7 - 2 stroke 12 cylinder 980 x 2.400 mm combustion engine - 72.240 kW at 104,0 rpm Year of manufacture: 2011 Manufacturer: Doosan Engine Co., Ltd. |
|
Propeller |
1x Solid propeller (keyless) - aft at 104,0 rpm |
|
Boilers |
1x Steam boiler, oil fired - 8,0 bar Heating surface:53,7 m² 1x Steam boiler, exhaust gas heated - 8,0 bar Heating surface: 660,0 m² Year of Manufacture: 2011 Manufacturer: Alfa Laval Qingdao Ltd. |
|
Electric installation |
2x Plants each 6.600 V - 3.500 kVA 2x Plants each 6.600 V - 4.750 kVA 1x Plant 6600 V - 4750 kVA 1x Plant 450 V - 375 kVA 2x Plants each 24 V - 4 Ah 2x Plants each 24 V - 4 Ah 2x Plants each 24 V - 24 Ah 2x Plants each 24 V - 24 Ah 2x Plants each 24 V - 24 Ah 2x Plants each 24 V - 215 Ah 2x Plants each 24 V - 400 Ah 12x Plants each 24 V - 2.400 Ah 12x Plants each 24 V - 2.400 Ah 2x Plants each 110 V - 585 Ah |
|
Generators |
2x Main diesel generatorsets each 4.750 kVA 2x Main diesel generatorsets each 3.500 kVA |
|
Emergency generator |
1x Diesel generatorset 375 kVA |
|
Batteries |
12x Batteries for UPS navigation each 2400 Ah 12x Batteries for UPS radio each 2400 Ah 2x Batteries for other purpose each 585 Ah 2x Batteries for diesel control each 400 Ah 2x Batteries for start emergency engine each 215 Ah 2x Batteries for other purpose each 24 Ah 2x Batteries for diesel control each 24 Ah 2x Batteries for start main engine each 24 Ah 2x Batteries for start emergency engine each 4 Ah 2x Batteries for other purpose each 4 Ah |
|
Compressed air receivers |
2x Receivers each 14.500 litres - 32,4 bar 1x Receiver 300 litres - 32,4 bar |
|
Bow thrusters |
2x Transverse thruster each 1.700 kW, forward |
|
Hatch type |
Steel pontoon |
|
Tank capacities |
Heavy fuel oil: 11,900 m³ Marine diesel oil: 500 m³ Lubricating oil: 600 m³ Fresh water: 500 m³ Ballast water: 35.000 m³ |
|
Anchor equipment |
3x Anchors weight each 24.500 kg Chain length: 770,00 m |
|
Cargo gear |
Gearless |
|
Crew |
34 |
|
Manager |
Reederei Claus-Peter Offen (GmbH & Co.) KG |
|
Operator |
CMA CGM - Compagnie Maritime D'Affrètement - Compagnie Générale Maritime |
|
Registered owner |
Kommanditgesellschaft MS "CPO TOULON" Offen Reederei GmbH & Co. |
|
Latest data adjustment |
22 February 2014 |
