Westerschelde 08 June 2020 |
 |
 |
|
| Westerschelde 28/07/20 | Westerschelde 28/07/20 | |
|
Name |
JETT |
|
Previous names |
2007 Launch as Balkan 2007 - 07/2008 CSAV Caribe 07/2008 - 2020 Balkan |
|
Type |
Containership |
|
IMO-number |
9358890 |
|
Call sign |
9HYK8 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
GT |
15.633 t Suez: 46.526,76 t |
|
DWT |
Summer: 17.004,69 t |
|
NT |
6.717 t Summer: 16.959 t |
|
Number of 20ft containers |
On deck: 812 In hold: 492 Total: 1.304 |
|
Container capacity 14t |
800 |
|
Reefer capacity |
On deck: 124 In hold: 126 250 plugs (440 V - 60 Hz - 3 phase) |
|
Length |
161,09 m overall 151,00 m between perpendiculars 151,35 m registered |
|
Breadth |
25,51 m extreme |
|
Draught |
Summer: 9,90 m |
|
Forecastle |
33,39 m |
|
Poop |
28,98 m |
|
Freeboard |
4.300 mm |
|
Depth |
13,90 m moulded |
|
Speed |
Max.: 19,0 knots |
|
Built |
2007 |
|
Keel laid |
20/12/2004 |
|
Launch date |
06/12/2006 |
|
Date of completion |
18/06/2007 |
|
Builder |
Shandong Province Weihai Shipyard 95 Haibin Road (N) 264200 Weihai, Shandong People's Republic of China |
|
Yard number |
CZ046 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Single hull Double bottom |
|
Watertight bulkheads |
7 |
|
Continuous decks |
1 |
|
Main engine |
1x MAN-B&W/Dalian 6S60MC-C - 2 stroke single acting 6 cylinder 600 x 2.400 mm combustion engine 13.560 kW / 18.395 bhp Manufacturer: STX Engine Co., Ltd. 80, Seongsan-dong Changwon , Gyeongsangnam 641-315 Republic of Korea |
|
Propellers |
1x Solid propeller (keyless) - aft |
|
Boilers |
1x Steam boiler, oil fired - 9,0 bar Heating surface: 19,0 m² 1x Steam boiler, exhaust gas heated - 9,0 bar Heating surface: 349,0 m² Year of manufacture: 2006 Manufacturer: Aalborg Industries Ltd. 86 Guangzhou Road North Jiaozhou 266300 Qingdao , Shandong People's Republic of China |
|
Electric installations |
3x Plants each 450/230 V - 1.200 kVA 1x Plant 450 V - 375 kVA |
|
Generators |
3x MaK 6M20 diesel generatorsets each 1.200 kVA |
|
Emergency generator |
1x Volvo D12D-A diesel generatorset 375 kVA |
|
Compressed air receivers |
2x Receivers each 6.000 litres - 30,0 bar 1x Receiver 320 litres - 30,0 bar 1x Receiver 1.000 litres - 10,0 bar 1x Receiver 320 litres - 10,0 bar |
|
Bow thruster |
1x Transverse thruster - 800 kW, forward |
|
Number of holds |
4x Holds divided in 8 compartments Dimension: Hold 1: 24,15 x 15,70 x 17,20 m, narrowing Holds 2-6: 12,48 x 20,70 x 14,30 m Hold 7: 6,24 x 20,70 x 14,30 m |
|
Hold capacity |
25.840,56 m³ |
|
Hold ventilation |
6x Air changes per hour |
|
Number of hatches |
8x Hatches with 14 hatch covers TTS pontoon type Dimensions: Hatches 1-2: 6,24 x 15,70 m Hatches 3-13: 6,24 x 20,70 m |
|
Hatch type |
Hatch covers are longitudinally divided for non-sequential opening and bay-wise operation also inside holds, it is not necessary to empty complete deck to reach containers in hold |
|
Tank capacities |
Fuel oil: 1.600 m³ Diesel oil: 150 m³ Ballast: 8.039,7 m³ Fresh water: 272,6 m³ |
|
Anchor equipment |
3x Anchors weight each 6.900 kg Length: 605,00 m Diameter: 64 mm |
|
Cargo gear |
2x Mac Gregor single deck container cranes: No. 1: 45 t / 26,00 m; 40 t / 29,00 m No. 2: 45 t / 31,00 m; 40 t / 35,00 m |
|
Crew |
20 |
|
Manager |
Bernhard Schulte Shipmanagement Ltd. Cyprus |
|
ISM Manager |
Bernhard Schulte Shipmanagement GmbH & Co., KG Germany |
|
Registered owner |
Laurel Shipping Ltd. Liberia |
|
Renamed |
10/2021 Skyview Liberia, Monrovia - Call sign: 5LBO7 Owner: Skyview Shipping Company Limited Manager: Midocean (IOM) Limited - Isle Of Man |
|
Latest data adjustment |
06 January 2023 |
