Westerschelde 12 October 2013 |
|
Name |
JOANNA BORCHARD |
|
Previous names |
06/2007 Max Linus Dede 08/2007 - 08/2008 Joanna Borchard 08/2008 - 02/2009 Max Linus Dede |
|
Type |
Containership |
|
IMO-number |
9354387 |
|
Call sign |
V2CL9 |
|
Flag |
Antigua & Barbuda |
|
Port of registry |
St. John's |
|
GT |
9.962 t |
|
DWT |
Summer: 11.433 t |
|
NT |
6.006 t |
|
Number of 20ft containers |
868 |
|
Container capacity 14t |
585 |
|
Reefer capacity |
204 |
|
Length |
134,44 m overall 125,08 m registered |
|
Breadth |
22,50 m registered |
|
Draught |
8,70 m |
|
Forecastle |
62,54 m |
|
Poop |
9,45 m |
|
Freeboard |
2.609 mm |
|
Depth |
11,30 m moulded |
|
Speed |
18,5 knots |
|
Built |
2007 |
|
Keel laid |
06/12/2004 |
|
Launch date |
16/03/2007 |
|
Date of completion |
31/05/2007 |
|
Builder |
J.J. Sietas KG Schiffswerft GmbH & Co. Neuenfelder Fährdeich 88 21129 Hamburg Federal Republic of Germany |
|
Yard number |
1237 |
|
Hull material |
Shipbuilding steel (standard) Higher tensile steel |
|
Hull type |
Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
4 |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 9M43C - 4 stroke 9 cylinder 430 x 610 combustion engine 8.400 kW at 500 rpm Starter type: Compressed air direct |
|
Propellers |
1x Controllable pitch propeller - aft at 128 rpm |
|
Boilers |
1x Thermal oil heater, oil fired - 10,0 bar Heating Surface: 45,4 m² 1x Thermal oil heater, exhaust gas heated - 10,0 bar Heating Surface: 183,0 m² Year of Manufacture: 2007 Manufacturer: ISW GmbH Industrie Service & Wärmeträgeranlagenbau Heinrich-Schröder-Str. 6 25436 Uetersen Federal Republic of Germany 1x Thermal oil heater, exhaust gas heated - 10,0 bar Heating Surface: 183,0 m² Year of Manufacture: 2007 Manufacturer: PWT Prozess-Wärmeträgertechnik GmbH Justus-von-Liebig-Ring 4-6 25451 Quickborn Federal Republic of Germany |
|
Electric installations |
1x Plant 400 V - 1.155 kVA 1x Plant 400 V - 1.390 kVA 1x Plant 400 V - 1.860 kVA 1x Plant 400 V - 400 kVA 2x Plants each 24 V - 140 Ah 1x Plant 400 V - 192 Ah |
|
Shaft generator |
1x 1.860 kVA |
|
Generators |
1x Caterpillar 3512 B DITA Diesel generatorset 1.390 kVA 1x Caterpillar 3508 B DITA Diesel generatorset 1.155 kVA |
|
Emergency generator |
1x Caterpillar 3408 DITA diesel generatorset 400 kVA |
|
Batteries |
1x Battery for emergency lighting 192 Ah 2x Batteries for start emergency engine each 140 Ah |
|
Compressed air receivers |
2x Receivers each 750 litres - 30,0 bar 1x Receiver 10 litres - 30,0 bar 1x Receiver 500 litres - 11,0 bar |
|
Bow thruster |
1x Transverse thruster 750 kW, forward 1x Transverse thruster 450 kW, aft |
|
Tank capacities |
Ballast: 3.932,8 m³ |
|
Anchor equipment |
3x Anchors weight each 5.250 kg Chain length: 577,50 m Diameter: 56 mm |
|
Crew size |
19 |
|
Manager |
Reederei Friedhelm Dede GmbH & Co. KG Esteburgring 2 21635 Jork Federal Republic of Germany |
|
Operator |
Borchard Line |
|
Registered owner |
MS "MAX LINUS DEDE" GmbH & Co. KG Esteburgring 2 21635 Jork Federal Republic of Germany |
|
Renamed |
2015 Max Linus Dede Antigua & Barbuda, St. John's - Call sign: V2CL9 Registered owner: MS "MAX LINUS DEDE" GmbH & Co. KG, Jork - Germany Manager: Reederei Dede, Jork - Germany 2016 Andante Portugal, Madeira - Call sign: CQBQ Regitered owner: MS "ANDANTE" Schiffahrtsgesellschaft mbH & Co. KG Manager: Reederei Friedhelm Dede GmbH & Co KG, Jork - Germany |
|
Latest data adjustment |
16 August 2024 |
