| Westerschelde 04 October 2011 |
 |
 |
 |
 |
|||
| Westerschelde 04/10/11 | Westerschelde 11/04/14 | Westerschelde 22/07/14 | Westerschelde 19/02/14 |
|
Name |
JOHANNA |
|
Type |
Containership |
|
IMO-number |
9197521 |
|
Call sign |
VQGQ2 |
|
Flag |
United kingdom |
|
Port of registry |
London |
|
GT |
6.363 t |
|
DWT |
7.131 t |
|
NT |
3.998 t |
|
Number of 20ft containers |
700 |
|
Reefer capacity |
144 |
|
Length |
121,35 m overall 114,90 m between perpendiculars 115,04 m registered |
|
Breadth |
18,20 m registered |
|
Draught |
6,69 m |
|
Forecastle |
76,30 m |
|
Poop |
9,05 m |
|
Freeboard |
1.620 mm |
|
Depth |
8,30 m moulded |
|
Speed |
Max.: 16,5 knots |
|
Built |
1999 |
|
Keel laid |
29.06.1998 |
|
Launch date |
26.10.1999 |
|
Date of completion |
10.12.1999 |
|
Builder |
J.J. Sietas KG Schiffswerft GmbH & Co. |
|
Yard number |
1071 |
|
Hull material |
Shipbuilding steel (higher tensile) |
|
Hull type |
Partly double bottom |
|
Watertight bulkheads |
6 |
|
Continuous decks |
1 |
|
Main engine |
1x MAN B&W 8 L 40/54 - 4 Stroke 8 cylinder 400 x 540 mm diesel engine - 5.300 kW at 514 rpm Reduced Power: 3.380 kW Year of manufacture: 1999 Manufacturer: MAN B&W Diesel GmbH |
|
Propeller |
1x Controllable pitch propeller - aft at 188 rpm |
|
Electric installations |
1x Plant 380/220 V - 380 kVA 1x Plant 380/220 V - 380 kVA 1x Plant 380 V - 1.100 kVA 1x Plant 380 V - 100 kVA |
|
Shaft generator |
1x 880 kW / 1.100 kVA |
|
Main generators |
2x Caterpillar 3408DI-TA main diesel generatorsets each 304 kW / 380 kVA |
|
Emergency generator |
1x Diesel generatorset 100 kVA |
|
Compressed air receivers |
2x Receivers each 500 litres - 30,0 bar |
|
Bow thruster |
1x Transverse thruster JASTRAM - 550 kW, forward |
|
Cargo capacity |
Grain: 13.852 m³ Bales: 12.536 m³ |
|
Tank capacities |
Fuel oil: 625 m³ Water ballast: 2.135 m³ |
|
Anchor equipment |
3x Anchors weight each 4.050 kg Chain length: 522,50 m |
|
Cargo gear |
None |
|
Crew size |
19 |
|
Manager |
Reederei Heinz-Georg Vöge |
|
Owner |
MS "JOHANNA" Heinz-Georg Vöge KG |
|
Renamed |
09.2014 Emilia - Portugal, Madeira - Call sing: CQGG |
|
Latest data adjustment |
12 February 2015 |
