Westerschelde 09 October 2014 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 24/06/15 | Westerschelde 24/06/15 | Doel, Belgium 29/08/17 | Doel, Belgium 29/08/17 | Westerschelde 28/08/17 | Westerschelde 18/09/15 | |||||
|
Name |
ESTELLE MAERSK (ESTELLE MÆRSK) |
|
Type |
Cellular containership |
|
IMO-number |
9321495 |
|
Call sign |
OVXO2 |
|
Flag |
Denmark |
|
Port of registry |
Hellerup |
|
GT |
171.542 t Suez: 171.347,16 t |
|
DWT |
Summer: 158.200 t |
|
NT |
62.537 t Suez: 151.109,93 t |
|
Number of 20ft containers |
13.460 |
|
Container capacity 14t |
11.000 |
|
Reefer capacity |
1.286 |
|
Length |
397,71m overall 376,00 m between perpendiculars |
|
Breadth |
56,40 m moulded 56,55 m extreme |
|
Draught |
Max.: 15,50 m |
|
Keel to mast end |
76,50 m |
|
Freeboard |
6.670 mm |
|
Depth |
30,20 m moulded |
|
Speed |
Max.: 25,5 knots |
|
Built |
2006 |
|
Keel laid |
08/04/2006 |
|
Launch date |
25/08/2006 |
|
Date of completion |
09/11/2006 |
|
Builder |
Odense Steel Shipyard Ltd. (Odense Staalskibsværft A/S) Odense Denmark |
|
Yard number |
L204 |
|
Hull material |
High strength steel Ordinary strength steel |
|
Bulkheads |
Water tight: 11 |
|
Main engine |
1x Wärtsilä/Doosan 14RT-FLEX96C - 2 stroke 14 cylinder 960 x 2.500 mm combustion engine 80.080 kW at 102,0 rpm Manufacturer: Doosan Engine Co. Ltd. |
|
Propellers |
1x Fixed pich six blade solid bronze propeller Manufacturer: Mecklenburger Metallguss GmbH |
|
Shaft motor |
2x Siemens AG - 4.500 kW each |
|
Boilers |
1x Vertical watertube oil fired auxiliary boiler AQ-10/12W - 14,0 bar 2x Exhaust gas boiler AV-6N - 12,0 bar 1x Unfired exhaust gas boiler - Mission XS 7V TC |
|
Generators |
1x Combo power / steam turbine generator - 10.625 kVA / 8.500 kW 5x MaK 9M32C diesel generatorsets each 5.925 kVA / 4.148 kW Manufacturer: Sem Drasov |
|
Emergency generator |
1x Diesel generatorset 50 kW |
|
Bow thruster |
2x Each 1.750 kW, forward 2x Each 1.750 kW, aft |
|
Number of holds |
23 |
|
Number of tanks |
Ballast: 31 Fuel oil: 22 Lubricating oil: 8 Sea water: 7 Fresh water: 7 Waste water: 6 Sludge: 6 Diesel oil: 6 Chain: 2 Hydraulic oil: 1 |
|
Tank capacities |
Diesel Oil: 405,00 m³ Freshwater: 752,60 m³ Fuel Oil: 16.920,30 m³ Hydraulic Oil: 5,70 m³ Lube Oil: 652,10 m³ Tank Ballast: 60.338,20 m³ |
|
Lifting equipment |
1x Monorail stores crane - SWL 20,0 t Manufacture: Dreggen A/S 2x Overhead engine room crane - SWL 12,5 t Manufacture: Danish Crane Building A/S 2x Stores/Bunker/ Suez-mob boat pedestal crane - SWL 5,0 t Manufacture: Dreggen A/S |
|
Cargo gear |
Gearless |
|
Manager |
AP Moller Maersk Esplanaden 50 DK-1098 København K Denmark |
|
Operator |
Maersk Line |
|
Registered owner |
Maersk A/S Esplanaden 50 1263 Copenhagen, K Denmark |
|
Latest data adjustment |
30 August 2024 |
