Westerschelde 18 February 2014 |
 |
 |
 |
 |
 |
||||
| Westerschelde 18/02/14 | Westerschelde 18/02/14 | Westerschelde 05/12/16 | Westerschelde 28/01/17 | Westerschelde 11/09/15 | ||||
|
Name |
MAERSK LABERINTO |
|
Type |
Cellular containership - Carriage of dangerous goods |
|
IMO-number |
9526978 |
|
Call sign |
OZJF2 |
|
Flag |
Denmark |
|
Port of registry |
København |
|
Previous names |
2012 - 06/2023 The Hong Kong Special Administrative Region of the People's Republic of China, Hog Kong - Call sign: VRKJ7 |
|
GT |
89.505 t registered Suez: 92.537,21 t |
|
DWT |
Summer: 99.900 t |
|
NT |
48.488 t registered Suez: 81.118,53 t |
|
Number of 20ft containers |
8.700 |
|
Reefer capacity |
1.707 |
|
Length |
299,90 m overall 286,80 m between perpendiculars |
|
Breadth |
45,20 m moulded |
|
Freeboard |
5.344 mm |
|
Speed |
Max.: 22,5 knots |
|
Built |
2012 |
|
Keel laid |
03/01/2012 |
|
Launch date |
18/03/2012 |
|
Date of completion |
13/05/2012 |
|
Builder |
Daewoo Shipbuilding & Marine Engineering Co. Ltd. Geoje South Korea |
|
Yard number |
4224 |
|
Hull material |
High strength steel Ordinary strength steel |
|
Watertight bulkheads |
13 |
|
Main engine |
1x MAN-B&W 9S90ME-C8 - 2 stroke 9 cylinder 900 x 3.188 mm combustion engine 45.740 kW / 62.188 hp at 78,0 rpm Manufacturer: Doosan Engine Co., Ltd. |
|
Propellers |
1x Fixed pitch propeller Manufacturer: Mecklenburger Metallguss GmbH - Germany |
|
Boilers |
Unfired Exhaust Gas Boiler - 10,0 bar Fired Boiler - 9,0 bar Manufacturer: Alfa Laval Qingdao Ltd. |
|
Auxiliary turbine generator |
1x Mitsubishi ATD52CLN2 - 4P - 3.700 kW Manufacturer: HHI Electro Electric System |
|
Generators |
1x MAN-B&W 6L32/40CD main diesel generatorset 2.800 kW 3x MAN-B&W 9L32/40CD main diesel generatorsets each 4.300 kW Manufacturer: HHI Electro Electric System |
|
Emergency generator |
1x Diesel generatorset 500 kW |
|
Bow thruster |
1x 2.300 kW |
|
Number of holds |
8 |
|
Number of tanks |
Ballast: 27 Fuel oil: 12 Lubricating oil: 10 Fresh water: 6 Diesel oil: 4 Waste water: 3 Sludge: 3 Organic compound: 1 Chain: 1 |
|
Tank capacities |
Diesel Oil: 723,4 m³ Freshwater: 522 m³ Fuel Oil: 9.082 m³ Lube Oil: 516,5 m³ Ballast: 33.566,6 m³ |
|
Lifting equipment |
Engine room crane - SWL 12,6 t (2x 6,3 t double jib engine room crane) Manufacture: Danish Crane Building |
|
Cargo gear |
Gearless |
|
Manager |
Maersk Line Esplanaden 50 DK-1098 København K Denmark |
|
Operator |
Maersk Line |
|
Registered owner |
Maersk A/S Esplanaden 50 126 København K Denmark |
|
Previous registered |
2012 - 06/2023 Maersk Shipping Hong Kong Limited Care of Rederiet A P Moller A/S, 1098 Copenhagen, K - Denmark |
|
Latest data adjustment |
20 August 2024 |
