Westerschelde 03 September 2015 |
 |
 |
|
| Westerschelde 01/02/16 | Westerschelde 01/02/16 | |
|
Name |
KALLIOPI R.C. |
|
Previous names |
1991 - 03/2015 Hoechst Express |
|
Type |
Cellular containership |
|
IMO-number |
8902565 |
|
Call sign |
D5IJ3 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
GT |
53.833 t |
|
DWT |
Summer: 67.751 t |
|
NT |
23.499 t |
|
Number of 20ft containers |
4.439 |
|
Container capacity 14t |
3.962 |
|
Reefer capacity |
452 |
|
Length |
294,11 m overall 283,70 m registered |
|
Breadth |
32,25 m registered |
|
Draught |
13,50 m |
|
Forecastle |
10,15 m |
|
Depth |
21,40 m moulded |
|
Speed |
23,0 knots |
|
Built |
1991 |
|
Keel laid |
27/05/1991 |
|
Launch date |
14/09/1991 |
|
Date of completion |
18/12/1991 |
|
Builder |
Samsung Shipbuilding & Heavy Industries Co., Ltd. 530, Jangpyung-ri, Sinhyun-up Koje-gun Republic of Korea |
|
Yard number |
1078 |
|
Hull material |
Shipbuilding steel (higher tensile) |
|
Hull type |
Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
8 |
|
Continuous decks |
2 |
|
Main engine |
1x MAN-B&W 9K90MC - 2 stroke 9 cylinder 900 x 2.550 mm combustion engine 36.510 kW / 49.639 hp at 93,0 rpm Year of manufacture: 1991 Manufacturer: Hyundai Heavy Industries Co., Ltd. 1, Cheonha-dong, Dong-gu Ulsan ,682-79 Republic of Korea |
|
Propellers |
1x Solid propeller (keyless) - aft at 93,0 rpm |
|
Boilers |
1x Steam boiler, oil fired - 10,0 bar Heating surface: 150,0 m² 1x Steam boiler, exhaust gas heated - 10,0 bar Heating surface: 1.253,0 m² Year of manufacture: 1991 Manufacturer: Aalborg Marine Boilers & Engineering A/S 9100 Aalborg Kingdom of Denmark |
|
Electric installations |
2x Plants each 450/ 220 V - 2.062 kVA 2x Plants each 450/ 220 V - 2.750 kVA 1x Plant 450 V - 438 kVA |
|
Generators |
2x Daihatsu main diesel generatorsets each 2.750 kVA 2x Daihatsu main diesel generatorsets each 2.062 kVA |
|
Emergency generator |
1x Diesel generatorset 438 kVA |
|
Compressed air receivers |
2x Receivers each 13.000 litres - 33,0 bar 1x Receiver 100 litres - 30,0 bar 1x Receiver 3.000 litres - 8,8 bar 1x Receiver 30 litres - 8,0 bar |
|
Bow thruster |
1x Fixed pitch propeller LIPS - 2.500 kW, forward |
|
Number of holds |
6 |
|
Number of hatches |
16 |
|
Tank capacities |
Fuel oil: 7.362 m³ Ballast water: 16.461 m³ |
|
Anchor equipment |
3x Anchors weight each 12.300 kg Chain length: 687,50 m |
|
Cargo gear |
Gearless |
|
Manager |
Marine Spirit (Management) S.A. |
|
Registered owner |
Fonseca Enterprises Inc. Morton House Government Road Charlestown St. Kitts-Navis |
|
Scrapped |
16/04/2023 beached at Alang - India |
|
Latest data adjustment |
21 September 2023 |
